11. TRANSPOSE

This function allows you to shift the pitch of the unit in semitones. You can transpose the pitch by 24 half steps (12

up, 12 down).

Press the TRANSPOSE switch. The LED shows the current TRANSPOSE value.

Press the “+” or “-” switch to change the TRANSPOSE value. Each time you press + or -, the keyboard is

transposed an additional half step.

* Pressing the + and - switches simultaneously resets the pitch to the default value.

Note: Turning the power off always resets the shifted pitch to the default value.

12. OCTAVE CHANGE

This function allows you to shift the pitch up to three octaves higher or two lower.

Press the OCTAVE UP or DOWN to change the octave range. The LED shows the new OCTAVE value.

* Press OCTAVE UP and DOWN switches simultaneously to reset the pitch to the default value.

Note: if the UP or DOWN switch is not pressed for 3 seconds, the LED will return to show the PROGRAM CHANGE

number.

13. Sending BANK MSB and LSB message

You can send any value of MSB or LSB from 0-127.

Press the BANK LSB switch. The LED starts to flash showing the current value of the LSB. Press the numeric keys

to change the LSB value. You can also use the “+” or “-” switches to change the value.

Press the BANK MSB switch. The LED starts to flash showing the current value of the MSB. Press numeric keys to

change the MSB value. You can also use the “+” or “-” switches to change the value.

Note: * if you don’t do anything for 3 seconds the LED stops flashing and shows the current PROGRAM CHANGE

number.

* if the number you input is over 127, it will return to the previous LSB or MSB value.
