Description

Installation.

• The heater should be situated at

least 1.8 meter above the floor.

Fig.2

• The plug and power cord should

be installed on height unavailable

for children.

• You need the following

for installation: 2 soft

inserts, 2 screws, 4 gaskets

(all mentioned you will find

in gift box). Fig.3.

• Please, insert the gaskets

into the holes in body. Fig. 4.

• You should make the holes in the wall on 57 cm from each other horizontally and at least on 2 m over

the floor. This way the heater should be at least on 1.8 m from the floor level. See fig. 2, 5 and 6

• The depth of the holes in wall should be 42-45 mm, of 8 mm diameter. The tighten screw should be

protruded from the wall on 18-20 mm.

Fig. 4

The hole for gasket

The hole for the gasket

Body

The hole for the screw

Soft

inserts

Gasket

Screws

Fig. 3

Fig 2

floor

Wall

Fig. 1

Remote control

Body

Swing leafs

Air inlet LED display

TIMER

button

unction

button
