Polaris PCWH 2063 Di [10/13] Function
![Polaris PCWH 2063 Di [10/13] Function](/views2/1019997/page10/bga.png)
• You may use cord keeper inside the heater if
the power cord is too long.
• After the heater installation, you should
tighten the screws.
Appliance operation
Remote control
• Observing polarity, insert the batteries into
the remote control.
• When pressing a button on the remote control, you will hear tones.
• When you will press the ON/OFF button, the indicator will light on, the fan will be turned on, the
swing leafs will be opened, and the air stream will go inside the room. You will see the inside
temperature on the display.
• When you will press the "HEATER“ button on the RC, starts the first heating mode – 1kW. If you
will press on the "HEATER“ button one more time, you will turn on the second heating mode – 2kW.
• Temperature setting. If you press the button, the temperature rises on 1 degree. The temperature
range is 18-45
0
С. If you already set the temperature on 45
0
С and press the button one more time. The
temperature will be set on 18
0
С.
• Setting of air flow swing. Press “Swing” button in order to turn this function on, press the button
one more time in order to turn in off.
• Air cleaning. If you will press the “ANION” button for one a time, the ionization function will be
activated. If you will press the button one more time, the function will be deactivated.
• Timer setting. Press the "TIMER" button on the RC in order to activate the timer. Each pressing on
the button increases timer time on 0.5 hour.
Attention! If you turn the heater off, the settings of timer will be deleted from the memory.
When you turn the heater off, it will work in the fan mode for 30 seconds in order to cool the heating
element.
The appliance operating with buttons on the body
Button
«function»
• Once you press the
«function»
button, you will hear the signal, the indicator will light on, the
fan will turn on, the swing leafs will open giving the air stream inside. The air temperature will be
shown on the display.
• If you will press the
«function»
button one more time, the first heating mode (1kW) will be
activated.
• If you will press the
«function»
button for the third time, the second heating mode (2kW) will be
activated.
• If you will press the
«function»
button for the fourth time, the swing function of air stream turns
on, the indicator “Swing” lights on.
The heater will turn off, if you press the
“function”
button for the fifth time.
If the heater operates
just in fan mode, the indicator of fan on the control panel lights out, all the functions stop to operate.
The indicator of fan will light on, when the heater operates in heating mode. When you turn the heater
off, it will work in the fan mode for 30 seconds in order to cool the heating element. The indicator will
light on for this time.
• You will turn on the setting of temperature if press the «function» button and keep it more then 3
seconds. The range of available temperature for setting is 18-45
0
С. The temperature will raise on 1
0
С
for each following press on the temperature button. При последующем однократном нажатии
кнопки установка температуры возрастает на 1
0
С. If you already set the temperature on 45
0
С and
press the button one more time. The temperature will be set on 18
0
С.
Fig 5
57cm
The distance between
the holes
Holes in wall
Wall
