Moxa V2406A-C2-T-W7E Технические характеристики онлайн
Railway Computers
1
www.moxa.com
V2406A Series
Compact, fanless, anti-vibration railway computers
The V2406A Series embedded computers are based on the Intel 3rd
generation processor, and feature 4 RS-232/422/485 serial ports,
dual LAN ports, audio in/out, 3 USB 2.0 hosts, 2 CFast sockets, and
1 SATA storage socket. The V2406A computers provide dual DVI-I
outputs, and in addition are compliant with a portion of EN 50155
specifications, covering operating temperature, power input voltage,
surge, ESD, and vibration, making the computers suitable for a variety
of industrial applications.
The dual megabit/gigabit Ethernet ports with M12 X-coded connectors
offer a reliable solution for network redundancy, promising continuous
operation for data communication and management. As an added
convenience, the V2406A computers have 6 DIs and 2 DOs for
connecting digital input/output devices, and the CFast feature provides
the reliability needed for industrial applications that require data
buffering and storage expansion.
Pre-installed with Linux Debian 7 or Windows Embedded Standard 7,
the V2406A Series provides programmers with a friendly environment
for developing sophisticated, bug-free application software at a low
cost. Wide temperature models of the V2406A Series that operate
reliably in a -40 to 70°C operating temperature range are also available,
offering an optimal solution for applications subjected to harsh
environments.
Appearance
Overview
Front View
› Intel Celeron/Core i7 processor suitable for diverse computing
demands
› Dual independent DVI-I displays
› 2 gigabit Ethernet ports with M12 X-coded connectors
› 1 SATA connector and 2 CFast sockets for storage expansion
› M12 A-coded power connector
› Compliant with EN 50121-4
› Complies with a portion of EN 50155 specifications
› Ready-to-run Windows Embedded Standard 7 or Linux Debian 7
› -40 to 70°C wide temperature models available
› Supports SNMP-based system configuration, control, and
monitoring (Windows Embedded Standard 7 only)
OS CFast
Socket
DVI-I
Outputs x 2
Audio
Output/Input
(M12 A-coded)
USB Hosts x 1
(M12 D-coded)
10/100/1000 Mbps
LAN Ports x 2
(M12 X-coded)
Power Switch
LEDs
(Power, Storage)
LAN LEDs
(10/100/1000 Mbps)
RTC Battery
Holder
