Railway Computers
1
www.moxa.com
Compact, fanless, anti-vibration railway computer
The V2426A Series embedded computers are based on the Intel 3rd
generation processor, and feature 4 RS-232/422/485 serial ports,
dual LAN ports, 3 USB 2.0 hosts, and dual DVI-I outputs. In addition,
the V2426A Series computers comply with a portion of EN 50155
specifications, covering operating temperature, power input voltage,
surge, ESD, and vibration, making them suitable for a variety of
industrial applications.
The dual megabit/gigabit Ethernet ports with M12 X-coded connectors
offer a reliable solution for network redundancy, promising continuous
operation for data communication and management. As an added
convenience, the V2426A computers have 6 DIs and 2 DOs for
connecting digital input/output devices. In addition, the CFast socket,
SATA connector, and USB sockets provide the V2426A computers
with the reliability needed for industrial applications that require data
Front View
buffering and storage expansion. Moreover, the V2426A computers
come with 2 peripheral expansion slots for inserting different
communication modules (2-port CAN module, or HSDPA, GPS, or
WLAN module), an 8+8-port digital input/output module, and a 2-port
serial module, giving greater flexibility for setting up different industrial
applications at field sites.
Pre-installed with Linux Debian 7 or Windows Embedded Standard 7,
the V2426A Series provides programmers with a friendly environment
for developing sophisticated, bug-free application software at a low
cost. Wide temperature models of the V2426A Series that operate
reliably in a -40 to 70°C operating temperature range are also available,
offering an optimal solution for applications subjected to harsh
environments.
V2426A Series
Overview
Appearance
› Intel Celeron/Intel Core i7 processor suitable for diverse
computing demands
› 2 peripheral expansion slots for various I/O, WLAN, mini-PCIe
expansion module cards
› Dual independent DVI-I displays
› 2 gigabit Ethernet ports with M12 X-coded connectors
› 1 SATA connector and CFast socket for storage expansion
› M12 A-coded power connector
› Compliant with EN 50121-4
› Complies with a portion of EN 50155 specifications
› Ready-to-run Windows Embedded Standard 7 or Linux Debian 7
platform
› -40 to 70°C wide temperature models available
› Supports SNMP-based system configuration, control, and
monitoring (Windows Embedded Standard 7 only)
OS CFast Socket
DVI-I
Outputs x 2
Expansion
Slots x 2
Power Switch
Audio
Input/Output
(M12 A-coded)
100/1000 Mbps
LAN Ports x 2 (M12 X-coded)
USB 2.0
Host (M12 D-coded)
System LEDs
(Power, Storage)
LAN LEDs x 4
RTC Battery Holder
