IV. Installation.
• The heater should be situated at
least 1.8 meter above the floor.
Fig.2
• The plug and power cord should
be installed on height unavailable
for children.
• You need the following
for installation: 2 soft
inserts, 2 screws, 4 gaskets
(all mentioned you will find
in gift box). Fig.3.
• Please, insert the gaskets
into the holes in body. Fig. 4.
• You should make the holes in the wall on
57,5 cm from each other horizontally and at
least on 2 m over the floor. This way the
heater should be at least on 1.8 m from the
floor level. See fig. 2, 5 and 6
• The depth of the holes in wall should be 42-
45 mm, of 8 mm diameter. The tighten screw
should be protruded from the wall on 18-20
mm.
• You may use cord keeper inside the heater if the power cord is too long.
• After the heater installation, you should tighten the screws.
V. Appliance operation
Remote control
• Observing polarity, insert the batteries into the remote control.
• When pressing a button on the remote control, you will hear tones.
• When you will press the ON/OFF button, the indicator will light on, the fan will be turned on, the
swing leafs will be opened, and the air stream will go inside the room. You will see the inside
temperature on the display.
• When you will press the "HEATER“ button on the RC, starts the first heating mode – 1kW. If you
will press on the "HEATER“ button one more time, you will turn on the second heating mode – 2kW.
• Temperature setting. If you press the button, the temperature rises on 1 degree. The temperature
range is 18-45
0
С. If you already set the temperature on 45
0
С and press the button one more time. The
temperature will be set on 18
0
С.
Fig. 4
The hole for gasket
The hole for the gasket
Body
The hole for the screw
Soft
inserts
Gasket
Screws
Fig. 3
Fig 2
floor
Wall
Fig 5
57
,5
cm
The distance between
the holes
Holes in wall
Wall
