Railway Computers
V2406 Series
x86 ready-to-run embedded computer with Intel Atom N270 CPU, VGA,
DVI-I, audio, 2 Ethernet LAN ports, 4 serial ports, 6 DIs, 2 DOs, 3 USB 2.0
ports, 1 CompactFlash slot
The V2406 Series embedded computers are based on the Intel Atom
N270 x86 processor, and feature 4 RS-232/422/485 serial ports,
dual LAN ports, and 3 USB 2.0 ports. V2406 computers provide VGA
and DVI-I outputs, and in addition are compliant with a portion of EN
50155 specifications, covering operating temperature, power input
voltage, power surges, ESD, and vibration, making them particularly
well-suited for railway and industrial applications.
The dual 10/100 Mbps Ethernet ports with M12 connectors offer
a reliable solution for network redundancy, promising continuous
operation for data communication and management. As an added
convenience, the V2406 computers have 6 DIs and 2 DOs for
connecting digital input/output devices, and the CompactFlash feature
provides the reliability needed for industrial applications that require
data buffering and storage expansion.
Pre-installed with a customized version of Debian Linux 5.0 ("Lenny"),
Windows Embedded Standard 2009, or Windows Embedded Standard
7, the V2406 Series provides programmers with a friendly environment
for developing sophisticated, bug-free application software at a low
cost. Wide temperature models of the V2406 Series that operate
reliably in a -40 to 70°C operating temperature range are also available,
offering an optimal solution for applications subjected to harsh
environments.
Appearance
Overview
Front View
› Intel Atom N270 1.6 GHz processor
› Up to 2 GB DDR2 533 SO-DIMM RAM
› Dual independent displays (VGA + DVI-I)
› 2 M12 Fast Ethernet ports, 10/100 Mbps
› 3 USB 2.0 ports for high speed peripherals
› 6 Digital Inputs, 2 Digital Outputs
› 1 CompactFlash slot for storage expansion
› 1 internal SATA-II storage drive bus
› M12 power connector
› Compliant with EN 50121-4 and a portion of EN 50155
specifications
› Ready-to-run Debian Linux 5.0, Windows Embedded Standard
2009, or Windows Embedded Standard 7 platform
› -40° to 70°C wide temperature models available
› 4 RS-232/422/485 serial ports (non-standard baudrates supported)
CF Socket
PS/2 VGA Output DVI-I Output
Audio
Output/Input
USB Port x 1
(M12)
10/100/1000 Mbps
Ethernet Port x 2 (M12)
Power Switch
LEDs
(Power, Storage)
LAN/USB Port
Pin Assignment
LAN LEDs
(100/1000 Mbps)
