V2406/2422/2426 Linux User’s Manual System Recovery
5-4
f. Make sure the first boot device is Hard Disk. If not, press Enter to change it.
g. Select Exit Save & Exit Setup and then press Enter.
h. Choose Y to save to the CMOS and then exit.
ATTENTION
Some USB disks will be regarded as a Removable Device. If this occurs, take the following steps.
i. Select Removable Device Priority.
