V2406/2422/2426 Linux User’s Manual Software Components
A-4
gstreamer0.10-plugins-bas
e
0.10.19-2 GStreamer plugins from the “base” set
gstreamer0.10-plugins-goo
d
0.10.8-4.1~lenny2 GStreamer plugins from the “good” set
gstreamer0.10-x 0.10.19-2 GStreamer plugins for X11 and Pango
gzip 1.3.12-6 The GNU compression utility
hal 0.5.11-8 Hardware Abstraction Layer
hal-info 20080508+git20080601-
1
Hardware Abstraction Layer - fdi files
hicolor-icon-theme 0.10-1 default fallback theme for FreeDesktop.org icon
themes
hostname 2.95 utility to set/show the host name or domain name
ifenslave 2 Attach and detach slave interfaces to a bonding
device
ifenslave-2.6 1.1.0-10 Attach and detach slave interfaces to a bonding
device
ifupdown 0.6.8+nmu1 high level tools to configure network interfaces
initramfs-tools 0.92o tools for generating an initramfs
initscripts 2.86.ds1-61 Scripts for initializing and shutting down the system
iproute 20080725-2 networking and traffic control tools
iptables 1.4.2-6 administration tools for packet filtering and NAT
iputils-ping 3:20071127-1 Tools to test the reachability of network hosts
iso-codes 3.5.1-1 ISO language, territory, currency, script codes and
their tran
klibc-utils 1.5.12-2 small utilities built with klibc for early boot
libaa1 1.4p5-37+b1 ascii art library
libacl1 2.2.47-2 Access control list shared library
libao2 0.8.8-4 Cross Platform Audio Output Library
libapache2-mod-php5 5.2.6.dfsg.1-1+lenny4 server-side, HTML-embedded scripting language
(Apache 2 module
libapm1 3.2.2-12 Library for interacting with APM driver in kernel
libapr1 1.2.12-5+lenny1 The Apache Portable Runtime Library
libaprutil1 1.2.12+dfsg-8+lenny4 The Apache Portable Runtime Utility Library
libart-2.0-2 2.3.20-2 Library of functions for 2D graphics - runtime files
libasound2 1.0.16-2 ALSA library
libaspell15 0.60.6-1 GNU Aspell spell-checker runtime library
libatk1.0-0 1.22.0-1 The ATK accessibility toolkit
libatk1.0-data 1.22.0-1 Common files for the ATK accessibility toolkit
libattr1 1:2.4.43-2 Extended attribute shared library
libaudiofile0 0.2.6-7+lenny1 Open-source version of SGI’s audiofile library
libavahi-client3 0.6.23-3lenny1 Avahi client library
libavahi-common-data 0.6.23-3lenny1 Avahi common data files
libavahi-common3 0.6.23-3lenny1 Avahi common library
libavahi-glib1 0.6.23-3lenny1 Avahi glib integration library
libavc1394-0 0.5.3-1+b1 control IEEE 1394 audio/video devices
libbeagle1 0.3.5-1+b1 library for accessing beagle using C
libbind9-40 1:9.5.1.dfsg.P3-1+lenny
1
BIND9 Shared Library used by BIND
libblkid1 1.41.3-1 block device id library
libbonobo2-0 2.22.0-1 Bonobo CORBA interfaces library
libbonobo2-common 2.22.0-1 Bonobo CORBA interfaces library -- support files
libbonoboui2-0 2.22.0-1 The Bonobo UI library
libbonoboui2-common 2.22.0-1 The Bonobo UI library -- common files
