3
www.moxa.com
info@moxa.com
Railway Computers
Software Specifications
Reliability
Automatic Reboot Trigger: Software-programmable watchdog timer
configurable from 1 to 255 seconds
MTBF (mean time between failures): 192,308 hrs
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
Note: These hardware specifications describe the embedded computer unit itself,
but not its official accessories. In particular, the wide temperature specification
does not apply to accessories such as power adaptors and cables.
Linux
OS: Debian Linux 5.0, “Lenny”, kernel 2.6.32
File System: EXT2
Internet Protocol Suite: TCP, UDP, IPv4, SNMPv1/v2c/v3, ICMP, ARP,
HTTP, CHAP, PAP, SSH 1.0/2.0, SSL, DHCP, NTP, NFS, Telnet, FTP,
TFTP, PPP, PPPoE
Internet Security: OpenVPN, iptables firewall
Web Server (Apache): Allows you to create and manage web sites;
supports PHP and XML
Terminal Server (SSH): Provides secure encrypted communications
between two un-trusted hosts over an insecure network
Dial-up Networking: PPP Daemon for Linux that allows Unix machines
to connect to the Internet through dialup lines, using the PPP protocol,
as a PPP server or client. Works with ‘chat’, ‘dip’, and ‘diald’, among
(many) others. Supports IP, TCP, UDP, and (for Linux) IPX (Novell).
File Server: Enables remote clients to access files and other resources
over the network
Watchdog: Features a hardware function to trigger system reset in a
user specified time interval (Moxa API provided)
Application Development Software:
• Moxa API Library (Watchdog timer, Moxa serial I/O control, Moxa DI/
DO API)
• GNU C/C++ compiler
• GNU C library
• Perl
Windows Embedded Standard 7
Core OS:
• 32-bit support
• Remote Client
• Remote Procedure Call
Applications and Services Development:
• .Net Framework 3.5
• Remote Desktop Protocol 7.1
• COM OLE Application Support
• COM+ Application Support
• MSMQ
Internet Services:
• Internet Explorer 8.0
• IIS 7.0
Diagnostics:
• Common Diagnostic Tools
• Problem Reports and Solutions
Fonts: Chinese (Trad. and Simp.), Japanese, Korean, Western, Middle
Eastern, South East Asian, and South Asian Fonts
Standards and Certifications
Safety: UL 60950-1, CSA C22.2 No. 60950-1-03, EN 60950-1
EMC: EN 55022 Class A, EN 61000-3-2 Class D, EN 61000-3-3, EN
55024, FCC Part 15 Subpart B Class A
Green Product: RoHS, CRoHS, WEEE
Rail Traffic: EN 50155*, EN 50121-3-2, EN 50121-4, IEC 61373
*Complies with a portion of EN 50155 specifications. Please contact Moxa or a
Moxa distributor for details.
Dimensions
Unit: mm (inch)
275 (10.83)
262.5 (10.33)
86 (3.39)
154 (6.06)
6 (0.24)
85.75 (3.38)
