Moxa MC-7130-MP Технические характеристики онлайн
1
www.moxa.com
info@moxa.com
Marine Displays and Computers
MC-7130-MP Marine Computer
optimal marine platform with diverse interface connectivity
The MC-7130-MP marine computer is powered by the latest 3rd
generation Intel
®
Core
™
i3 3120ME processor. Optimized for ECDIS,
these computers can serve in nearly any bridge role thanks to their
comprehensive range of I/O and communications interfaces: eight
NMEA 0183 terminals, four serial ports, four gigabit Ethernet ports,
six USB 2.0 and three SuperSpeed USB 3.0 ports. The MC-7130-MP is
designed to give unrivalled PC performance for a new level of flexibility
and control for marine applications.
Designed with the highest quality and durability in mind, the marine-
grade MC-7130-MP computer features a rugged chassis and vibration
tolerance up to 1G, together providing a highly reliable platform that
can easily tolerate the harsh environmental challenges of marine
environments. Additionally, the MC-7130-MP’s compact size
and low power consumption return a low heat profile that increases
MTBF while simplifying integration into existing bridge systems or
newly designed marine solutions.
Finally, the MC-7130-MP also offers convenient connectivity
expansions via a single PCIe (x16) slot and two universal PCI slots,
allowing users to install a variety of peripheral extensions for radar,
PROFIBUS, VGA graphics, and more, allowing for direct consolidation
of all input sources at a single hub.
The MC-7130-MP platform is optimized for use with the Windows
XP Embedded, XP Professional, or Windows 7 operating systems,
allowing users to choose the development environment most suitable
for the application’s needs.
Appearance
Overview
Front View
› High performance computing platform with 3rd gen Intel
®
Core
™
i3
3120ME processor
› Optimized solution with modularized NMEA interfaces
› DNV and ABS certified
› Trusted Platform Module provides data and hardware security
integrated at the hardware level
› Blistering fast graphics performance across 3 independent displays
LPT Port
(Dongle)
2. x USB 2.0
(type A)
Removable
Storage Slot
Protection Lock
Power Button
System LEDs
(Power, Storage)
Reset Button
