1
www.moxa.com
Marine Displays and Computers
MPC-2190 Series
Introduction
Appearance
19-inch ECDIS color calibrated, fanless panel computers
MPC-2190 panel computers feature an Intel 3rd generation processor
matched to 4 GB of system memory, delivering a reliable, high-
performance platform of wide versatility for use in industrial marine
environments. With its two RS-232/422/485 serial ports, four NMEA
0183 ports, and two Gigabit Ethernet LAN ports, the MPC-2190
panel computer supports a wide variety of serial and marine-specific
interfaces as well as high speed IT communications, all with native
network redundancy.
The MPC-2190 series comes with a range of standard display
enhancements useful in industrial environments (including full range
dimming, wide viewing angles, and optional optical bonding), as well
as a few innovations especially deployed for maritime environments:
user-friendly OSD controls, called SavvyTouch, featuring a proximity
sensor for convenient adjustment in dark situations, immediate
BIOS-level reports on hardware status (useful for determining why
a machine will not boot up), and a quick-switch ECDIS button (for
color-calibrated ECDIS models only) that allows instant brightness
adjustments to any of the three pre-set calibrations dictated by the
ECDIS standard. In addition to all of this, the MPC-2190 series features
a modular design that makes device integration into either new or
existing industrial systems much simpler, reducing deployment costs
and overall time-to-market.
The MPC-2190 panel computers are compliant with several industrial
marine standards, including IEC 60945, IEC 61162, IEC 61174, DNV,
and IACS E10, verifying their resilience for maritime operations. The
IP54 (front panel) and IP22 (rear panel) rated unibody shell provides
strong additional protection against the harsh conditions found in
marine environments.
Color-calibrated ECDIS models are available upon request, providing
an ideal HMI alternative for ECDIS charting and navigation stations.
DC Power Input
AC Power Input
RS-232/422/485
Port x 2
DVI-D/VGA
Output
NMEA 0183 Port x 4
Line in/out
SavvyTouch Display
Control Button x 5
Panel
USB 2.0 x 4
Gigabit LAN x 2
Keyboard/Mouse
Connectors
Grounding
Connector
Buzzer
› 19-inch panel computer
› Color calibrated for ECDIS compliance
› Fanless system design with FloTHERM®
› SavvyTouch™ Controls
› 3rd Generation Intel® Core™ to Celeron® processor (Celeron®
1047UE, 1.40 GHz, and Intel® Core i7 2610UE 1.5 GHz)
› Built-in NMEA 0183 and 3-in-1 software selectable RS-
232/422/485 interfaces
› Multi-power supplies (AC & DC)
