Cuckoo LH-5311FN Liiot [27/40] Name of each part

Name of each part

Spray outlet

Adjust direction so that spray can’t face the human

body or furniture, and use product.

Don’t use without the spray outlet.

Install the upper spray outlet to the lower outlet and

turn it as you want to have the mist then power on.

Clean it 2-3 times every week.

Upper spray outlet

Lower spray outlet

Water tank

Give full attention because it can

get damaged even by weak shock.

Powdered silver composed in

water tank so it prevents microbe

growing in the water

Ventilating outlet

Detachable spray filter

equipped

Serves as spray passage.

Detachable spray filter in a water

tank filters fog and sprays out

minute fog to keep a pleasant

condition. Be sure to attach a

spray filter to the water tank for

a household use.

Especially at the time of clean-

ing, give full attention so that

water can’t go into it.

Oscillator

Water-spraying device.

Water tank section

Don’t operate the unit when the

water is empty in the water tank

section.

Plug

Control section

Refer to functional description

of control section.

Cleaning brush

Clean oscillator by

cleaning brush.

Dust-removing air filter

Filters dust of air which goes

into the floor or product.

Remove dust 2-3 times every

week.

Water tark cover

Fasten cover so that water

can’t leak after you have put

water into water tank.

Ion water filter

There’s impurities like Mg,

Ca etc. in normal water the

Ion filter makes it clean and

better water to be sprayed

out.

Level sensor

Stops spray automatically if water

tank is short of water.

The main body

Give full attention so that water

can’t go into the inside of the main

body.

“Open” Button

Device which splits water tank from

the main body and puts it into the

main body.
