25
P0118
Engine Coolant Temperature Sensor 1 Circuit High
P0119
Engine Coolant Temperature Sensor 1 Circuit Intermittent
P011A
Engine Coolant Temperature Sensor 1/2 Correlation
P011B
Engine Coolant Temperature/Intake Air Temperature Correlation
P011C
Charge Air Temperature/Intake Air Temperature Correlation Bank 1
P011D
Charge Air Temperature/Intake Air Temperature Correlation Bank 2
P0120
Throttle/Pedal Position Sensor/Switch "A" Circuit
P0121
Throttle/Pedal Position Sensor/Switch "A" Circuit Range/Performance
P0122
Throttle/Pedal Position Sensor/Switch "A" Circuit Low
P0123
Throttle/Pedal Position Sensor/Switch "A" Circuit High
P0124
Throttle/Pedal Position Sensor/Switch "A" Circuit Intermittent
P0125
Insufficient Coolant Temperature for Closed Loop Fuel Control
P0126
Insufficient Coolant Temperature for Stable Operation
P0127
Intake Air Temperature Too High
P0128
Coolant Thermostat (Coolant Temperature Below Thermostat Regulating
Temperature)
P0129
Barometric Pressure Too Low
P012A
Turbocharger/Supercharger Inlet Pressure Sensor Circuit
Downstream of throttle valve
P012B
Turbocharger/Supercharger Inlet Pressure Sensor Circuit Range/Performance
Downstream of throttle valve
P012C
Turbocharger/Supercharger Inlet Pressure Sensor Circuit Low
Downstream of throttle valve
P012D
Turbocharger/Supercharger Inlet Pressure Sensor Circuit High
Downstream of throttle valve
P012E
Turbocharger/Supercharger Inlet Pressure Sensor Circuit Intermittent/Erratic
Downstream of throttle valve
P0130
O2 Sensor Circuit Bank 1 Sensor 1
P0131
O2 Sensor Circuit Low Voltage Bank 1 Sensor 1
P0132
O2 Sensor Circuit High Voltage Bank 1 Sensor 1
P0133
O2 Sensor Circuit Slow Response Bank 1 Sensor 1
P0134
O2 Sensor Circuit No Activity Detected Bank 1 Sensor 1
P0135
O2 Sensor Heater Circuit Bank 1 Sensor 1
P0136
O2 Sensor Circuit Bank 1 Sensor 2
P0137
O2 Sensor Circuit Low Voltage Bank 1 Sensor 2
P0138
O2 Sensor Circuit High Voltage Bank 1 Sensor 2
P0139
O2 Sensor Circuit Slow Response Bank 1 Sensor 2
P013A
O2 Sensor Slow Response - Rich to Lean Bank 1 Sensor 2
P013B
O2 Sensor Slow Response - Lean to Rich Bank 1 Sensor 2
P013C
O2 Sensor Slow Response - Rich to Lean Bank 2 Sensor 2
P013D
O2 Sensor Slow Response - Lean to Rich Bank 2 Sensor 2
P013E
O2 Sensor Delayed Response - Rich to Lean Bank 1 Sensor 2
P013F
O2 Sensor Delayed Response - Lean to Rich Bank 1 Sensor 2
P0140
O2 Sensor Circuit No Activity Detected Bank 1 Sensor 2
P0141
O2 Sensor Heater Circuit Bank 1 Sensor 2
P0142
O2 Sensor Circuit Bank 1 Sensor 3
P0143
O2 Sensor Circuit Low Voltage Bank 1 Sensor 3
P0144
O2 Sensor Circuit High Voltage Bank 1 Sensor 3
