Autel MaxiCheck Oil Light/Service Reset [57/63] B auto reset

B. Auto Reset

Most American and European vehicles can be reset automatically by

the scan tool.

NOTE: In this manner, the scan tool will communicate with

the vehicle being tested. If there is a linking error, please

refer to 3.8 product troubleshooting.

To finish this procedure, please follow these steps (Taking

Volkswagen as an example):

1) From the vehicle make screen, select Volkswagen and press

OK button.

Figure 7.5

2) From the Oil Reset menu, select Auto Reset option and press

OK button.

Figure 7.6

Oil Reset

1.Manual Reset

2.Auto Reset
