 If you record live data under graph mode, following screen

shows:

Figure 5.17

NOTE: The scan tool can only playback text data even

though the data is saved in graphic mode.

2) When there is not enough memory space, a warning message

prompting to delete previously recorded data.

Figure 5.18

 If you wish to delete the data, select Yes and save currently

retrieved data in the SD card.

 If you do not wish to delete the data, select No to return to

previous screen.

Save Failure

Memory space not enough!

Erase previously recorded

Data?

Yes No
