Autel MaxiCheck EPB [55/59] Figure 7

3) Connect the tool to vehicle and power on.

4) Turn the ignition on.

5) Select EPB icon in the Main Screen (Figure 3.1) and wait for

the vehicle manufacturer screen. Choose the correct vehicle

make. (Take BENZ as an example)

Figure 7.1

6) After you have selected the vehicle make (BENZ), the

electrical parking brake system screen will display as below.

Figure 7.2

7) In the EPB diagnostic function, the tool can read codes, erase

codes, record live data, read ECU information, and perform

active test. For the functions already being described before,

such as read/clear codes, live data, and ECU information,

please refer to chapter 5. OBDII Diagnostics for details.

Diag. Menu

1. Read Codes

2. Erase Codes

3. Live Data

4. Active Test

5. ECU Information
