Moxa ICF-1170I-M-ST-T [2/2] Ordering information

Serial Media Converters

2

© Moxa Inc. All rights reserved. Updated Apr. 15, 2016. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

Ordering Information

Physical Characteristics

Housing: Metal

Dimensions: 30.3 x 70 x 115 mm (1.19 x 2.76 x 4.53 in)

Weight: 178 g (0.39 lb)

Environmental Limits

Input Voltage: 12 to 48 VDC dual power for redundant power

Input Current:

ICF-1170I: 221 mA @ 12 VDC

Alarm Contact: 1 relay output with current-carrying capacity of 1 A @

24 VDC

Voltage Reversal Protection: Protects against V+/V- reversal

Overcurrent Protection: 1.1 A (protects against two signals shorted

together)

Standards and Certifications

Safety: UL 508

EMC: EN 55022/24

EMI: CISPR 22, FCC Part 15B Class A

EMS:

EN 61000-4-2 (ESD): Contact: 8 kV; Air: 15 kV

Freefall: IEC 60068-2-32

MTBF (mean time between failures)

Time: 792,085 hrs

Standard: Telcordia (Bellcore), GB

Warranty

Warranty Period: 5 years

Details: See www.moxa.com/warranty

Available Models

ICF-1170I-M-ST: CAN-to-fiber converter, multi-mode, ST connector, 0 to 60°C

ICF-1170I-M-ST-T: CAN-to-fiber converter, multi-mode, ST connector, -40 to 85°C

Package Checklist

• 1 ICF-1170I CAN-to-fiber converter

• Quick installation guide (printed)

• Warranty card

8.8 [0.35]
