Remote I/O
2
www.moxa.com
ioLogik E1510-T Specifications
ioLogik E1512-T Specifications
Inputs and Outputs
Digital Inputs: 12 channels (channel-to-channel isolation)
Isolation: 3k VDC or 2k Vrms
Digital Input
Sensor Type: Wet Contact (NPN or PNP), Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to GND):
• On: 0 to 3 VDC
• Off: 10 to 30 VDC
Inputs and Outputs
Digital Inputs: 4 channels (channel-to-channel isolation)
Configurable DIOs (by software): 4 channels
Isolation: 3k VDC or 2k Vrms
Digital Input
Sensor Type: Wet Contact (NPN or PNP), Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to GND):
• On: 0 to 3 VDC
• Off: 10 to 30 VDC
Common Type: 2 points per COM (Configurable DIOs)
Counter Frequency: 250 Hz
Digital Filtering Time Interval: Software configurable
Counter Frequency: 250 Hz
Digital Filtering Time Interval: Software configurable
MTBF (mean time between failures)
Time: 507,064 hrs
Standard: Telcordia SR332
Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 500 Hz
Over-Voltage Protection: 45 VDC
Over-Current Protection: 2.6 A (4 channels @ 650 mA)
Over-Temperature Shutdown: 175°C (typical), 150°C (min.)
Current Rating: 200 mA per channel
MTBF (mean time between failures)
Time: 554,122 hrs
Standard: Telcordia SR332
ioLogik E1510-T Specifications
Do you need an EN 50155/50121 compliant remote Ethernet I/O
device for use on rolling stock? The ioLogik E1500 railway I/O module
features an anti-vibration design, channel isolation, and operates
reliably in temperatures ranging from -40 to 85°C, making it the
ideal solution for data acquisition on rolling stock. Capable of both
monitoring system status and triggering I/O events, the ioLogik E1500
is your best choice when you want to simultaneously enhance system
reliability and maintenance efficiency in rolling stock environments.
Application: Enhanced Efficiency for Remote Monitoring on Rolling Stock
