Remote I/O
3
www.moxa.com
ioLogik 2542 Specifications
Inputs and Outputs
Configurable DIOs (by software): 12 channels
Analog Inputs: 4 channels
Isolation: 3k VDC or 2k Vrms
Digital Input
Sensor Type: Wet Contact (NPN or PNP) and Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to COM):
• On: 10 to 30 VDC
• Off: 0 to 3 VDC
Common Type: 6 points per COM
Counter Frequency: 2.5 kHz
Digital Filtering Time Interval: Software configurable
Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 5 kHz
Over-Voltage Protection: 45 VDC
Over-Current Protection: 1.5 A per channel @ 25°C
Over-Temperature Shutdown: 175°C (min.)
Current Rating: 500 mA per channel @ 25°C
DIO Output Leakage Current: < 1 mA @ 30 VDC
Analog Input
Type: Differential input
Resolution: 16 bits
I/O Mode: Voltage / Current (software selectable)
Input Range: ±10 V, 0 to 10 V, 0 to 20 mA, 4 to 20 mA, 4 to 20 mA
(burnout detection)
Accuracy:
• ±0.1% FSR @ 25°C
• ±0.3% FSR @ -10 and 60°C
• ±0.5% FSR @ -30 and 70°C
Sampling Rate:
• All channels: 400 samples/sec
• Per channel: 100 samples/sec
Input Impedance: 1 mega-ohm (min.)
Built-in Resistor for Current Input: 120 ohms
Power Requirements
Input Voltage: 9 to 48 VDC
Input Current: 358 mA @ 24 VDC
MTBF (mean time between failures)
Time: 375,439 hrs
Standard: Telcordia SR332
Common Specifications
LAN
Ethernet:
• 4 switched 10/100 Mbps RJ45 ports
• 1 optimized port for faster downstream communications with
daisy-chained ioLogik E1200 units
Note: The optimized daisy-chain port is not supported by the ioLogik E1261W-T,
E1261H-T, or E1263H-T.
Protection: 1.5 kV magnetic isolation
Protocols: Modbus/TCP (slave), TCP/IP, UDP, DHCP, BOOTP, SNMP,
HTTP, CGI, SNTP, SMTP
Serial
Interface: 2 RS-232/422/485 (software selectable) RJ45 ports
Parity: None, Odd, Even
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 2
Flow Control: None, RTS/CTS, XON/XOFF
Baudrate: 300 to 115200 bps
Protocols: Modbus/RTU (master/gateway), serial tunnel mode (client/
server)
Physical Characteristics
Wiring: I/O cable max. 14 AWG
Dimensions: 61 x 157 x 115 mm (2.4 x 6.18 x 4.53 in)
Weight: Under 1265 g (2.79 lb)
Mounting: DIN-rail (standard), wall (with optional kit)
Storage
Expansion Slot: Up to 32 GB microSD™ memory card (SDHC
compatible)
Note: For units operating in extreme temperatures, industrial-grade, wide-
temperature SD cards are required.
Inputs and Outputs
Digital Inputs: 8 channels
Configurable DIOs (by software): 8 channels
Isolation: 3k VDC or 2k Vrms
Digital Input
Sensor Type: Wet Contact (NPN or PNP) and Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to COM):
• On: 10 to 30 VDC
• Off: 0 to 3 VDC
Common Type: 8 points per COM
Counter Frequency: 2.5 kHz
Digital Filtering Time Interval: Software configurable
Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 5 kHz
Over-Voltage Protection: 45 VDC
Over-Current Protection: 1.5 A per channel @ 25°C
Over-Temperature Shutdown: 175°C (min.)
Current Rating: 500 mA per channel @ 25°C
DIO Output Leakage Current: < 1 mA @ 30 VDC
Power Requirements
Input Voltage: 9 to 48 VDC
Input Current: 274 mA @ 24 VDC
MTBF (mean time between failures)
Time: 467,032 hrs
Standard: Telcordia SR332
ioLogik 2512 Specifications
