Overview

Moxa’s ioLogik 2500 series remote I/O products are designed for general

applications. The ioLogik 2500 can be daisy chained with up to 8 other I/O

modules (such as the ioLogik E1200) to create a large and distributed I/O

array, with the ioLogik 2500 providing wireless communications for the

entire chain. For I/O expansion, each ioLogik 2500 series has a

designated port to support the daisy-chaining of up to 8 ioLogik E1200

devices, all controlled by Click&Go Plus.

Equipped with Click&Go Plus, the ioLogik 2500 series provides

easy-to-use front-end control logic for alarms, peer-to-peer connections,

and data logging. Unlike traditional I/O servers, which are passive and

must be polled by the SCADA system, when used with Moxa’s MX-AOPC

UA Server the ioLogik 2500 series uses active messaging to “push” state

changes or configured events to the SCADA system, when occur.

Model Information

• I/O combinations

DIO

ioLogik 2512

–

ioLogik 2542

–

For more I/O combinations, the ioLogik 2500 can be daisy chained

with up to 8 other I/O modules.

• Communication interface

Communication Interface

ioLogik 2500

Serial / Ethernet

ioLogik 2500-GPRS

Serial / Ethernet / GPRS (2G)

ioLogik 2500-HSPA

Serial / Ethernet / GPRS (2G) / HSPA (3G)

ioLogik 2500-WL1

Serial / Ethernet / Wireless LAN

Package Checklist

• ioLogik 2500 series device

• 3-pin screw terminal block (for power input)

• 2 12-pin screw terminal blocks (for I/O)

• 2 8-pin RJ45-to-DB9 cables (CBL-RJ45M9-150)

• 1 antenna (only for wireless modules)

• Documentation and software CD

• Hardware installation guide (printed)
