7
7. Software Lock
“Software Lock” is an innovative technology developed by Moxa. It can be adopted by a system integrator or
developer to protect his applications from being copied. An application is compiled into a binary format bound
to the embedded computer and the operating system (OS) that the application runs on. As long as one obtains
it from the computer, he/she can install it into the same hardware and the same operating system. The add-on
value created by the developer is thus lost.
Moxa used data encryption to develop this protection mechanism for your applications. The binary file
associated with each of your applications needs to undergo an additional encryption process after you have
developed it. The process requires you to install an encryption key in the target computer.
1. Choose an encryption key (e.g.,”ABigKey”) and install it in the target computer by a pre- utility program,
‘setkey’.
#setkey ABigKey
NOTE: set an empty string to clear the encryption key in the target computer by:
#setkey ““
2. Develop and compile your program in the development PC.
3. In the development PC, run the utility program ‘binencryptor’ to encrypt your program with an encryption
key.
#binencryptor yourProgram ABigKey
4. Upload the encrypted program file to the target computerby FTP or NFS and test the program.
The encryption key is a computer-wise key. That is to say, a computer has only one key installed. Running
the program ‘setkey’ multiple times overrides the existing key.
To prove the effectiveness of this software protection mechanism, prepare a target computer that has not
been installed an encryption key or install a key different from that used to encrypt your program. In any
case, the encrypted program fails immediately.
This mechanism also allows the computer with an encryption key to bypass programs that are not
encrypted. Therefore, in the development phase, you can develop your programs and test them in the
target computer cleanly.
