Moxa C Programmable RTU Controllers Getting Started
2-6
Grounding the RTU Controller
The Moxa C programming RTU Controller is grounded to enhance EMS performance. The RTU controller comes
with a metal DIN-Rail bracket for grounding the system. For optimal EMS performance, connect the chassis
ground nut on the RTU controller to the grounding point.
ioPAC 8020-C Series
ioLogik W5348 Series:
Powering on the RTU Controller
Connect the 12 to 36 VDC power lines from the power supply to the Moxa C programming RTU controller’s
power terminal block, and then power on the power supply attached to it. It takes about 30 to 60 seconds for
the system to boot up. Once the system is ready, the Ready LED will light up.
Power Terminal Block for ioLogik W5348-C Series
Grounding Nut
Grounding Nut
