1
www.moxa.com
info@moxa.com
Programmable RTU Controllers
Millisecond Timestamps
Millisecond timestamp level of accuracy gives engineers a powerfully.
For example, if an emergency triggers 10 separate I/O events within
a 10-millisecond time interval, you will still be able to clearly identify
the sequence in which the events occurred, even if the I/O events are
recorded by different modules.
ioPAC 5542 Series
Specifications
Rugged, compact RTU controllers
› Dedicated ARM CPUs for both the main system and I/O channels
› Millisecond timestamp granularity on both digital input and
analog input
› Up to 250 Hz (per channel) sampling rate
› Prerecord feature for analog input data logging
› Supports C/C++ or IEC 61131-3 programming languages
› Compliant with EN 50121-4, UL/cUL Class 1 Division 2
› Robust and compact design for harsh environments
The ioPAC 5500 standalone controllers use an ARM9 industrial grade
CPU for the main system, with ARM Cortex™ M4 based CPUs used
for I/O channels. The USB bus between the controller CPU and module
CPUs transmits data at up to 200 Mbps, and the dual CPU architecture
supports up to a 250 Hz per channel analog input sampling rate with
millisecond timestamp granularity. The ioPAC 5500 supports C/C++
programming langauges, rail-level surge and ESD protection, a -40 to
75°C (-30 to 75°C for HSPA models) operating temperature range, UL/
cUL Class 1 Division 2 certifications, two 10/100 Mbps Ethernet ports
with two MACs (Port Trunking ready), and two 3-in-1 serial ports.
With Moxa’s Active OPC Server and DA-Center, the ioPAC 5500 series
provides a comprehensive solution for data acquisition and control
applications in harsh environments.
Overview
Computer
Main CPU: 32-bit ARM9 192 MHz CPU
I/O CPU: 32-bit ARM Cortex M4 80 MHz CPU
OS: Linux
Clock: Real-time clock with battery backup
Memory:
• SDRAM: 64 MB
• Flash: 32 MB
• SRAM: 256 KB (battery backup lasts for 1 week)
• microSD™ Slot: Up to 32 GB (SD 2.0 compatible)
Note: For units operating in extreme temperatures, industrial grade, wide-
temperature microSD cards are required.
Cellular (for the ioPAC 5542-HSPA Series)
Network:
• Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz
• Five-band UMTS/HSPA+ 800/850/AWS/1900/2100 MHz
Internet:
HSPA:
• Up to 5.76 Mbps upload speed
• Up to 14.4 Mbps download speed
UMTS: Up to 384 kbps upload/download speed
EDGE Class 12: Up to 237 kbps upload/download speed
GPPRS Class 12: Up to 85.6 kbps upload/download speed
SMS: Point-to-Point Text/PDU mode
SIM Control Voltage: 3/1.8 V
Specifications
Moxa’s ioPAC 5542 RTUs use an ARM9
industrial-grade CPU, and the dual CPU
architecture supports up to 250 Hz/ch analog
input sampling rate, giving engineers the analog
data precision they need to correctly analyze
events, and then formulate the best response.
The ioPAC 5542’s prerecord function allows the
RTU controller to continuously record analog
input data before an event trigger point. The
prerecording function is a major improvement
over products that only start data logging after
an event has occurred, which can lead to the
loss of critical data due to the latency between
the event and when the data logging actually
begins.
High Sampling Rate Prerecorded analog input
