2
Industrial Cellular Solutions
© Moxa Inc. All Rights Reserved. Updated Apr. 15, 2016. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
Dimensions
Unit: mm (inch)
Ordering Information
Available Models
OnCell G3111: 1-port quad-band industrial GSM/GPRS IP gateway, RS-232, -30 to 55°C operating
temperature
OnCell G3151: 1-port quad-band industrial GSM/GPRS IP gateway, RS-232/422/485, -30 to 55°C
operating temperature
OnCell G3211: 2-port quad-band industrial GSM/GPRS IP gateway, RS-232, -30 to 55°C operating
temperature
OnCell G3251: 2-port quad-band industrial GSM/GPRS IP gateway, RS-232/422/485, -30 to 55°C
operating temperature
Note: Please visit Moxa’s website for a complete list of optional wireless accessories and antennas available for
Moxa’s wireless products.
Package Checklist
• OnCell G3xx1 IP gateway
• 1 GSM/GPRS antenna: ANT-CQB-
ASM-01
• Rubber stand
• DC power supply (screw-on type)
• DIN-rail kit
• Documentation and software CD
• Quick installation guide (printed)
• Warranty card
Note: An activated SIM card (not included)
must be provided by a third party Cellular
Service Provider.
OnCell G3211,
OnCell G3251
OnCell G3111,
OnCell G3151
Front & Rear ViewTop & Bottom View Left & Right Side View
Weight:
OnCell G3111/G3151: 170 g (0.38 lb)
OnCell G3211/G3251: 190 g (0.42 lb)
Dimensions: 77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in)
Environmental Limits
Operating Temperature: -30 to 55°C (-22 to 131°F)
Storage Temperature: -40 to 75°C (-40 to 167°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Power Requirements
Number of Power Inputs: 1 power jack
Input Voltage: 12 to 48 VDC
Input Current: 0.9 A @ 12 VDC; 0.23 A @ 48 VDC
Standards and Certifications
Safety: UL 60950-1
EMC: EN 55022/24
EMI: CISPR 22, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power 1 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
Radio: FCC Part 22H, FCC Part 24E, EN 301 489-1, EN 301 489-7,
EN 301 511, PTCRB (OnCell G3151 only)
MTBF (mean time between failures)
Time:
OnCell G3111: 664,000 hrs
OnCell G3151: 661,000 hrs
OnCell G3211: 647,000 hrs
OnCell G3251: 642,000 hrs
Standard: Telcordia SR332
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
DB9 male connector
PIN RS-232 RS-422/485-4w RS-485-2w
1 DCD TxD-(A) –
2 RxD TxD+(B) –
3 TxD RxD+(B) Data+(B)
4 DTR RxD-(A) Data-(A)
5 GND GND GND
6 DSR – –
7 RTS – –
8 CTS – –
9 – – –
1 2 3 4 5
6 7 8 9
77 (3.03)
111 (4.37)
100 (3.94)
26 (1.02)
