IW Accessories
1
© Moxa Inc. All Rights Reserved. Updated Dec. 14, 2011. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
ANT-WCDMA-ASM-1.5
Five-band GSM/GPRS/EDGE/UMTS/HSPA, 1.5 dBi, omni-directional,
rubber duck antenna
Specifications
Ordering Information
Antenna Characteristics
Frequency: 850/900/1800/1900/2100 MHz
Anntenna Type: Omni-directional
Typical Antenna Gain: 1.5 dBi
Connector: SMA (male)
Impedance: 50 ohms
Polarization: Linear, vertical
HPBW/horizontal: 360°
V.S.W.R.: <2
Physical Characteristics
Weight: 10 g
Dimensions: Length=104 mm
Radome Color: Black
Radome Material: Plastic
Installation: Straight mount
Environmental Limits
Operating Temperature: -30 to 75°F (-22 to 167°F)
Storage Temperature: -30 to 75°C (-22 to 167°F)
Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)
Warranty
Warranty Period: 1 year
Details: See www.moxa.com/warranty
87±1
Ø9.3
Ø8
26.4
Dimensions
Unit: mm (inch)
Available Models
ANT-WCDMA-ASM-1.5: Five-band GSM/GPRS/UMTS/HSDPA, omni-directional, 1.5 dBi, rubber SMA
Can be used with the following products
OnCell G2111/G2151I, OnCell G3111/G3151, OnCell G3211/G3251, OnCell G3100 Series, OnCell G3100-HSDPA Series, OnCell G3100-HSPA
Series, OnCell 5000 Series, OnCell 5000-HSDPA Series, OnCell 5000-HSPA Series
› Small size for compact fit
› Lightweight for portable deployment
› Tilt and swivel design
› Flexible installation
› SMA connector (male) supported
