- 22 -
Power
Input
VPort 26A-1MP: 1, 12/24 VDC or 24 VAC with
2-pin terminal block connector
VPort P26A-1MP: 1, Power-over-Ethernet
(IEEE802.3af)
Consumption
• VPort 26A-1MP: 4.7 W
• VPort P26A-1MP: 5.8 W
Local stroage
SD Socket
Standard SD socket (SDHC)
Physical Properties
Housing
Metal, IP66 rated for rain and dust protection,
vandal-resistant
Dimensions
Diameter: 149 mm (5.7 in)
Height: 120 mm (4.7 in)
Weight
1.4 kg (0.64 lb)
Installation
Surface mounting, or outdoor mounting with
accessories
Environmental Limits
Operating Temperature
Standard models: -40 to 50°C (-40 to 122°F )
Wide temp. models: -40 to 75°C (-40 to
167°F )
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
UL
UL 60950-1
EMI
FCC Part 15, CISPR (EN55022) class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8
EN61000-4-11
Shock
IEC60068-2-27
Freefall
IEC60068-2-32
Vibration
IEC60068-2-6
Vandal-resistant
EN 62262, IK10 level
Warranty
5 years
MTBF (mean time between failures)
Time
201,721 hrs
Database
Telcordia (Bellcore), 25°C
Alarm Features
• Intelligent Video: Camera tamper
• Video motion detection with sensitivity tuning
• Video loss alarm
• Daily repeat timing schedule
• JPEG snapshots for pre/trigger/post alarm images
• Automatic transfer of stored images via email or FTP as
event-triggered actions
• HTTP event servers and CGI events for setting customized alarm
actions
• 24 MB pre-alarm video buffer for JPEG snapshot images
