Moxa VPort P26A-1MP-T [2/4] Specifications

Moxa VPort P26A-1MP-T [2/4] Specifications
IP Surveillance
2
www.moxa.com
Specifications
Camera
Sensor: 1/2.7” HD progressive scan CMOS
Lens: Focal length = 3 to 9 mm, F = 1.2
Auto Iris Type: DC drive
Camera Angle (controlled manually):
• Pan: ±175°, Tilt: 0 to 85°
• Rotation: PAN: ±180°
Minimum Illumination:
• Color: 0.2 lux at F1.2
• B/W: 0.05 lux at F1.2
Synchronization: Internal
White Balance: ATW/AWB (range: 3200 to 10000°K)
Electronic Shutter: Auto, 1/30 to 1/25,000 sec.
Dynamic Range:
• Color: 100 db
• B/W: 110 db
S/N Ratio: 50 dB (Gamma, Aperture, AGC OFF, DNR ON)
ICR Control: Auto
DNR: Built-in DNR (digital noise reduction)
WDR: Level 1-8/ off
AGC Control: 2X, 4X, 8X, 16X, 32X, 64X
Flickerless Control: Indoor/Outdoor modes
Black Level Control: High, Medium, Low
Auto Exposure: Level ±5
Image Rotation: Flip, Mirror, and 180° rotation
Image Setting: Manual tuning with saturation, sharpness, and contrast
Video
Video Compression: H.264 (ISO/IEC 14496-10) or MJPEG
Video Output: Via Ethernet
Video Streams: 3 video streams (2 x H.264, 1 x MJPEG)
Video Resolution and FPS (frames per second):
NTSC PAL
Size Max. FPS Size Max. FPS
QCIF
176 x 112 30 176 x 144 25
QVGA
320 x 240 30 320 x 240 25
CIF
352 x 240 30 352 x 288 25
VGA
640 x 480 30 640 x 480 25
4CIF
704 x 480 30 704 x 576 25
Full D1
720 x 480 30 720 x 576 25
SVGA
800 x 600 30 800 x 600 25
HD
1280 x 720 30 1280 x 720 25
Note: Mulitple streams may not support up to 30 FPS.
Video Viewing:
• DynaStream™ supported for changing the video frame rate
automatically
• CBR Pro™ for good image quality in limited bandwidth transmission
• 3 privacy mask areas provided
• Adjustable image size and quality
• Timestamp and text overlay
• Maximum of 5 simultaneous unicast connections
• ROI (Region of Interest) conguration for up to 3 areas
PTZ: Digital PTZ with 4X zoom
Audio
Audio Inputs: 1 line-in with 2-pin terminal block connector
Audio Outputs: 1 line-out with 2-pin terminal block connector
Network
Protocols: TCP, UDP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP,
UPnP, RTP, RTSP, ICMP, IGMPv3, QoS, SNMPv1/v2c/v3, DDNS,
Modbus/TCP, 802.1X, SSH/HTTPS
Ethernet: 1 10/100BaseT(X) Ethernet port, RJ45 connector
GPIO
Digital Inputs: 1, max. 8 mA
• High: +13 V to +30 V
• Low: -30 V to +3 V
Relay Outputs: 1, max. 24 VDC @ 1 A
LED Indicators
STAT: Indicates if the system is booted properly or not
Network: 10 Mbps or 100 Mbps
Power: Power on/off
DIP Switch: To turn the LED light on/off
Local Storage
SD Socket: Standard SD socket (SDHC)
Power Requirements
Power Input:
• VPort 26A-1MP: 1, 12/24 VDC or 24 VAC
• VPort P26A-1MP: Power-over-Ethernet (PoE, IEEE 802.3af)
Power Consumption:
• VPort 26A-1MP: 4.7 W
• VPort P26A-1MP: 5.8 W
Physical Characteristics
Housing: Metal, IP66 rated for rain and dust protection, vandal-proof
Dimensions: 149 mm (diameter) x 120 mm (height)
Installation: Surface mounting, or outdoor mounting with accessories
Alarms
Intelligent Video: Tamper alarm
Video Motion Detection: Includes sensitivity settings
Scheduling: Daily repeat timing schedule
Imaging: JPEG snapshots for pre/trigger/post alarm images
Custom Alarms: HTTP event servers and CGI events for setting
customized alarm actions
Email/FTP Messaging: Automatic transfer of stored images via email
or FTP as event-triggered actions
Pre-alarm Buffer: 24 MB video buffer for JPEG snapshot images
Security
Password: User level password protection
Filtering: By IP address
Authentication: 802.1X
Encryption: HTTPS, SSH
Environmental Limits
Operating Temperature:
Standard models: -40 to 50°C (-40 to 122°F )
Wide temp. models: -40 to 75°C (-40 to 167°F )
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 60950-1
Railway:
EN50121-4: 2006 (VPort 26A-1MP series)
EMI: FCC Part 15, CISPR (EN 55022) class A
EMS:
EN 61000-4-2 (ESD), Level 3,
EN 61000-4-3 (RS), Level 3,
EN 61000-4-4 (EFT), Level 3,
EN 61000-4-5 (Surge), Level 3,
EN 61000-4-6 (CS), Level 3,
EN 61000-4-8
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Vandal Resistance: EN 62262, IK10 level
