VPort 36-1MP Introduction

1-3

• Screw handle accessory package

Inner hexagon screw driver for

tightening/loosening lens holder

C/CS mount adapter ring

pin terminal block for DI and

relay

3-pin terminal block for power

input

2-pin terminal block for RS-485 DX+

and DX-

• Quick installation guide

• Documentation and software CD (includes User’s Manual, Quick Installation Guide, and VPort Utility)

• Warranty card

NOTE: Notify your sales representative if any of the above items are missing or damaged.

NOTE

Check the model name on the VPort’s side label to determine if the model name is correct for your order.

NOTE

This product must be installed in compliance with your local laws and regulations.

Product Features

• Sensor: 1/2.7” HD progressive scan CMOS

• Lens: C/CS mount lens (lens not included)

• Auto Iris Type: DC drive (Not for Hazardous Location)

• Illumination (low light sensitivity):

 Color: 0.2 lux at F1.2

 B/W: 0.05 lux at F1.2

• Synchronization: Internal

• Gamma Correction: 0.45 or 1.0 (default 0.45)

• White Balance: ATW/AWB (range: 3200 to 10000°K)

• Dynamic Range: Color: 100 dB; B/W: 110 dB

• Auto Electronic Shutter: 1/30 to 1/25000 sec.

• S/N Ratio: 50 dB (Gamma, Aperture, AGC OFF; DNR ON)

• ICR Control: Auto (light sensor control) or DI control

• DNR: Built-in DNR

• WDR: On/Off

• AGC Control: On/Off

• Flickerless Control: On/Off

• Auto Exposure: -5 to +5 level

• Image Rotation: Flip, Mirror, and 180° rotation

• Image Setting: Manual tuning with brightness, saturation, contrast, and sharpness
