- 11 -
Video
Video Compression
H.264 (ISO/IEC 14496-10) or MJPEG
Video Output
Via Ethernet
Video Streams
Maximum of 3 video streams (2x H.264 and 1x
MJPEG)
Stream 1: H.264, max. resolution 1280x720
Stream 2: H.264, max. resolution 720x480
Stream 3: MJPEG, max. resolution 720x480
Note: Streams 2 and 3 must be the same resolution.
Video Resolution
and FPS
NTSC
PAL
Size
Max.
FPS
Size
Max.
FPS
QCIF
176 x 120
30
176 x 144
25
CIF
352 x 240
30
352 x 288
25
VGA
640 x 480
30
640 x 480
25
4CIF
704 x 480
30
704 x 576
25
Full D1
720 x 480
30
720 x 576
25
SVGA
800 x 600
30
800 x 600
25
HD
1280 x 720
30
1280 x 720
25
Up to 30/25 FPS for each of 3
independent streams
at max. resolution.
Video Viewing
•
DynaStream™ supported for changing the
video frame rate automatically
• 3 privacy mask areas provided
• Adjustable image size and quality
• Timestamp and text overlay
• Maximum of 10 simultaneous unicast
connections
•
ROI (Region of Interest) configuration for up to
3 areas
PTZ
Digital PTZ
Network
Protocols
TCP, UDP, HTTP, SMTP, FTP, Telnet, NTP, DNS,
DHCP, UPnP, RTP, RTSP, ICMP, IGMPv3, QoS,
SNMPv1/v2c/v3, DDNS, Modbus/TCP, 802.1X,
SSH/SSL
Ethernet
1 10/100BaseT(X) Ethernet port, RJ45 connector
Standard
OnVIF
Local Storage
SD socket
Standard SD socket (SDHC)
GPIO
Digital input
1, max. 8mA
Low: +13V to +30V
High: -30 to +3V
Relay output
1, max. 24 VDC @ 1 A
Serial Interface
RS-485
1 full-duplex RS-485 port
LED Indicators
STAT
Indicates if the system booted properly or not
Network
10 Mbps or 100 Mbps
Power
Power on/off
Power
Input
12 VDC, 24 VDC, 24 VAC or Power over Ethernet
(PoE, 802.3af)
