- 10 -
Wiring Requirements
Safety First!
•
Be sure to disconnect the power cord before installing and/or
wiring your Moxa VPort 36-1MP.
•
Calculate the maximum possible current in each power wire
and common wire, and obs
erve all electrical codes dictating
the maximum current allowable for each wire size.
•
If the current exceeds the maximum ratings, the wiring could
overheat, resulting in serious damage to your equipment.
You should also pay attention to the following:
• Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
• You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring that shares similar electrical characteristics can be
bundled together.
• Keep input wiring and output wiring separated.
• We strongly advise labeling the wiring to all devices in the system.
Specifications
Camera
Sensor
1/2.7” HD progressive scan CMOS
Lens
C/CS mount lens
Auto Iris Type
DC drive (lens not included with product)
Illumination
Color: 0.2 lux at F1.2
B/W: 0.05 lux at F1.2
Synchronization
Internal
White Balance
ATW/AWB (range: 3200 to 10000 ºK)
Wide Dynamic
Range
Color: 100 dB
B/W: 110 dB
Electronic Shutter AES: 1/30 to 1/25,000 sec
Fixed: 1/50, 1/10
0, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000 sec
Gamma Correction
0.45 or 1.0 (default is 0.45)
S/N Ratio
50 dB (Gamma, Aperture, AGC OFF, DNR ON)
ICR control
Auto (light sensor control) or DI control
DNR
Built-in
WDR
On/Off
AGC Control
On/Off
Flickerless Control
On/Off
Backlight
Compensation
On/Off
Auto Exposure
On/Off
Image Rotation
Flip, Mirror, and 180° rotation
Image Setting
Manual tuning of brightness, saturation, contrast,
and sharpness
Содержание
- Quick installation guide 1
- Third edition october 2013 1
- Vport 36 1mp series 1
- Overview 2
- Package checklist 2
- Features 3
- Product description 4
- Hardware installation 6
- Software installation 7
- Step 1 configure the vport 36 1mp s ip address 7
- Step 2 access the vport 36 1mp s web based manager 8
- Step 3 install the activex control plug in 8
- Step 4 access the homepage of the vport 36 1mp s 9
- Step 5 access the vport s system configuration 9
- Web based manager 9
- Specifications 10
- Wiring requirements 10
