- 5 -

Network Environment with DHCP Server

When DHCP is active, the unit’s IP address will be assigned by the

network’s DHCP server. Refer to the DHCP server’s IP address table to

determine the unit’s assigned IP address. You may also use the Moxa

VPort and EtherDevice Configurator Utility (edscfgui.exe), as described

below:

Using the Moxa VPort and EtherDevice Configurator Utility

(edscfgui.exe)

1. Run the edscfgui.exe program to search for the VPort. After the

utility’s window opens, you may also click on the Search button

to initiate a search.

2. When the search has concluded, the Model Name, MAC address, IP

address, serial port, and HTTP port of the VPort will be listed in the

utility’s window.

3. Double click the selected VPort or use the IE web browser to access

the VPort’s web-based manager (web server).

Non DHCP Server Network Environment

If your VPort 36-2L is connected to a network that does not have a DHCP

server, then you will need to configure the IP address manually. The

default IP address of the VPort 36-2L is 192.168.127.100 and the default

subnet mask is 255.255.255.0. Note that you may need to change your

computer’s IP address and subnet mask so that the computer is on the

same subnet as the VPort.

To change the IP address of the VPort manually, access the VPort’s web

server, and then navigate to the System Configuration  Network 

General page to configure the IP address and other network settings.

Check the Use fixed IP address option to ensure that the IP address you

assign is not deleted each time the VPort is restarted.

Step 2: Accessing the VPort 36-2L’s web-based manager

Type the IP address in the web browser’s address input box and then

press enter.
