IP Surveillance
2
www.moxa.com
Dimensions
Unit: mm (inch)
Top ViewBottom View Side View
Video Viewing:
• DynaStream™ support for automatic frame rate adjustment
• CBR Pro™ for good image quality in limited bandwidth transmission
• 3 privacy mask areas congurable
• Adjustable image size and quality
• Timestamp and text overlay
• OSD (On screen Display) position adjustable
• Maximum of 5 simultaneous unicast connections
Audio
Audio Inputs: 1, Line-in, rugged RCA connector; or 1 bulit-in
microphone input
Audio Format: Mono, PCM (G.711)
Network
Protocols: TCP/IP, UDP, HTTP, SMTP, NTP, DNS, DHCP, UPnP, RTP,
RTSP, ICMP, QoS,IGMPv3, SNMPv1/v2c/v3, DDNS, TFTP, ARP, DHCP,
OPT66/67
Ethernet: 1 10/100BaseT(X) isolated Ethernet port, 4-pin M12 D-coded
female connector
Power Requirements
Input: Power-over-Ethernet (IEEE 802.3af)
Power Consumption: 6 W (max.)
Physical Characteristics
Housing: IP66 rain and dust protection, EN 62262 IK9 vandal-proof
protection
Dimensions: Diameter: 110 mm (4.33 in); Height: 47 mm (1.85 in)
Weight: 310 g (0.68 lb)
Installation: Surface or ceiling mounting
Note: Optional external housing and mounting accessories may be required.
Alarms
Intelligent Video: Camera tamper
Video Motion Detection: 3 independently configurable motion areas
Scheduling: Daily repeat timing schedule
Imaging: JPEG snapshots for pre/trigger/post alarm images
Custom Alarms: HTTP event servers for setting customized alarm
actions
Email/FTP Messaging: Automatic transfer of stored images via email
or FTP as event-triggered actions
Security
Password: User level password protection
Filtering: By IP address
Encryption: HTTPS, SSH
Environmental Limits
Operating Temperature:
Standard model: -25 to 55°C (-13 to 131°F)
Wide Temp. model: -40 to 70°C (-40 to 158°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 60950-1
Rail Traffic: EN 50155 (essential compliance*), EN 45545-2
*Moxa defines “essential compliance” to include those EN 50155 requirements
that make products more suitable for rolling stock railway applications.
EMC: EN 55022/24
EMI: CISPR 22, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
Shock: IEC 61373
Freefall: IEC 60068-2-32
Vibration: IEC 61373
Vandal Resistance: EN 62262, IK9 level
Fire Protection: EN 45545-2: 2013
MTBF (mean time between failures)
Time: 1,944,687 hrs
Standard: Telcordia TR/SR
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Minimum Viewing System Requirements
CPU: Pentium 4, 2.4 GHz
Memory: 512 MB of memory
OS: Windows XP/2000 with SP4 or above, Windows Vista, Windows 7
Browser: Internet Explorer 9.x or above
Multimedia: DirectX 9.0c or above
Software Development
VPort SDK PLUS: Includes CGI commands, ActiveX Control, and API
library for customized applications or system integration for third-party
developers (the latest version of SDK is available for download from
Moxa’s website).
Standard: ONVIF Prole S
33°
16°
Ø4.5
Ø96
Ø110
Ø110
46.6
