IP Surveillance
1
www.moxa.com
VPort P16-1MP-M12 Series
EN 50155 compliant, HD video image, rugged IP cameras
The rugged VPort P16-1MP-M12 cameras provide an HD (720P, 1280
x 720) video image, and feature an H.264/MJPEG IP dome, giving them
the versatility and ruggedness to excel in many different installations and
environments for mobile IP video surveillance applications. In addition,
the cameras are compliant with essential sections of EN 50155, covering
operating temperature, power input voltage, surge, ESD, and vibration,
as well as conformal coating and power insulation, making them
suitable for a variety of industrial applications, and feature vandal-
proofing (EN 62262 IK10), a -25 to 55°C or -40 to 70°C (T models)
operating temperature, a rugged M12 Ethernet port, PoE power inputs,
IP66 rain and dust protection, and day & night image capability.
Introduction
Specifications
› Essential compliance with EN 50155* (T1 temperatures: -25
to 55°C; TX temperatures: -40 to 70°C), and compliant with EN
50121-3-2
› 1/2.7” progressive scan camera with maximum 1280 x 800
resolution at up to 30 frames per second
› Built-in light sensor for day & night images
› High quality video images with DNR and WDR
› Up to 3 H.264 or MJPEG independent video streams
› DynaStream™ supported for network efficiency
› CBR Pro™ supported for high image quality in limited bandwidth
transmissions
› Supports DHCP Opt 66/67 for auto-configuration
› ONVIF supported for standardization and interoperability
*Moxa defines “essential compliance” to include those EN 50155 requirements
that make products more suitable for rolling stock railway applications.
Camera
Sensor: 1/2.7” HD progressive scan CMOS
Lens: 3.6, 8 mm fixed focal length
Angle of View:
• 3.6 mm, F1.6: Diagonal 120°, Horizontal 96°, Vertical 56°
• 8.0 mm, F1.8: Diagonal 48°, Horizontal 38°, Vertical 24°
Illumination (low light sensitvity):
• Color: 0.2 Lux @ F1.2
• B/W: 0.05 Lux @ F1.2
Camera Angle: Pan 350°, Tilt 80° (controlled manually)
ICR Control (for day & night): Auto
Synchronization: Internal
White Balance: ATW/AWC
Electronic Shutter: Auto, fixed (1/30 to 1/25000 sec)
S/N Ratio: 50 dB (Gamma, Aperture, AGC, OFF; DNR ON)
DNR: Built-in
WDR: Levels 1-8, up to 155 dB
AGC Control: 2X, 4X, 8X, 16X, 32X, 64X
Flickerless Control: Automatic/50 Hz/60 Hz
Auto Exposure: Level ±5
Image Rotation: Flip, Mirror, and 180° rotation
Image Setting: Manual tuning with saturation, sharpness, and contrast
Black Level Control: High/Medium/Low
Video
Video Compression: H.264 (ISO/IEC 14496-10) or MJPEG
Video Output: Via Ethernet
Video Streams: 3 independent H.264 or MJPEG video streams
Video Resolution and FPS (frames per second):
NTSC PAL
Size Max. FPS Size Max. FPS
QCIF
176 x 112 30 176 x 144 25
QVGA
320 x 240 30 320 x 240 25
CIF
352 x 240 30 352 x 288 25
VGA
640 x 480 30 640 x 480 25
4CIF
704 x 480 30 704 x 576 25
Full D1
720 x 480 30 720 x 576 25
SVGA
800 x 600 30 800 x 600 25
HD
1280 x 720 30 1280 x 720 25
WXGA
1280 x 800 30 1280 x 800 25
Video Viewing:
• CBR Pro™ for good image quality in limited bandwidth transmissions
• DynaStream™ supported for automatic frame rate adjustment
• 3 congurable privacy mask areas
• Adjustable image size and quality
• Timestamp and text overlay
• OSD (On screen Display) position adjustable
• Maximum of 5 simultaneous unicast connections
