Custom PTZ Camera Commands

In addition to the default pan, tilt, zoom, and focus controls, an additional 24 buttons are available for custom

commands to control the attached motorized (PTZ) cameras. Custom commands are set up by administrators,

and are used for functions such as activating or deactivating the dome wiper. Refer to the attached motorized

device’s user’s manual to see which functions can be controlled with these additional buttons.

Snapshot

You can take snapshot images for storing, printing, and editing by clicking the Snapshot button. To save the

image, right-click and select the Save option.

Relay Control (not supported for all VPorts)

Some VPort models have relay outputs for external devices, such as alarms. Administrators and permitted

users can click on Acitve (Open) to short the Common and Normal Open digital output pins, or click on

Deactive (Close) to short the Common and Normal Close digital output pins.
