IP Surveillance
1
www.moxa.com
VP-022D
H.264 1080P real-time IP video decoder
The VPort VP-022D is a video decoder for decoding up to four H.264
video streams simultaneously from VPort video encoders and IP
cameras to a digital signal. The digital signal can be transmitted via
the VP-022D’s HDMI port to monitors for live-view displaying. The
VP-022D is a simple monitoring solution for displaying live images in
locations where only a live video display is required, such as a control
room or guard house. Monitoring multiple cameras in a large CCTV
system is also easy with the VP-022D. A virtual matrix streaming
layout can be arranged by the user, hanging your displayed IP video
steams is very easy and flexible, and up to 16 IP video sources can be
included in the device list. The VP-022D also has four keyholes on its
base designed for wall-mounting applications for easy installation.
Specifications
Introduction
› Decodes H.264 vido streams to an HDMI video signal
› View up to 4 split screens on a single monitor
› Manual selection of up to 16 video sources
› Transparent PTZ control with legacy PTZ controller
› Supports VPort encoders and VPort IP cameras
Video
Video Decoding: H.264 (MPEG4 part 10)
Video Inputs: Accepts video streams from VPort encoders and IP
cameras over TCP/IP networks
Video Output: HDMI connector (1.3a Type A), 1080P output
Stream Multiplexor: 1 to 4, split screen
Video Sources: Up to 16, selected manually by web server or monitor
interface
Audio
Audio Outputs: 1 RCA audio connector
Network
Protocols: ARP, TCP, IP, UDP, HTTP, DDNS, RTSP, RTCP, SNMP v1
v2
Ethernet: 1 10/100/1000BaseT(X) auto negotiating RJ45 port
Serial Port
Keyboard Input: 1 RJ45 port; supports RS-485 control via transparent
PTZ
Mouse Input: USB, right-mouse-click, mouse wheel
GPIO
Relay Outputs: 1, 30 VDC (max.) @ 1 A
LED Indicators
Power: Constant-on if powered up
Reset: Reset to factory defaults
Act: Network ACT LED
Link: Network LINK LED
Power Requirements
Input: 1.5 A @ 12 VDC
Power Consumption: 18 W
Physical Characteristics
Housing: Metal
Dimensions: 180 x 130 x 43 mm (7.09 x 5.12 x 1.69 in)
Weight: 500 g (1.1 lb)
PTZ (Pan/Tilt/Zoom)
PTZ Camera Control: Transparent PTZ camera control with legacy PTZ
controller through RS-485 PTZ port
Security
Password: User-level password protection
Environmental Limits
Operating Temperature: 0 to 50°C (32 to 122°F)
Ambient Relative Humidity: 0 to 80%
Standards and Certifications
EMI: CISPR 22, FCC Part 15B Class A
Emission:
EN 55022:2010 Class A
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Immunity:
IEC 50130-4:2011
IEC 61000-4-2:2008
IEC 61000-4-3:2006+A1: 2007+ A2: 2010
IEC 61000-4-4:2012
IEC 61000-4-5:2014
IEC 61000-4-6: 2013
IEC 61000-4-11: 2004
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
