- 19 -
process will run, and the VPort will reboot. The STAT LED will light in
green when the VPort has finished rebooting.
Specifications
Video
Video Compression
H.264 (MPEG4 Part 10, AVC), MJPEG
Video Streams
2 (1 H.264 and 1 MJPEG)
Video Inputs
4, BNC connector (1 Vpp, 75 ohms)
Video Latency
Under 200 ms
NTSC/PAL
Manual
Video Resolution and FPS (frames per second):
NTSC
PAL
Size
Max. FPS
Size
Max. FPS
QCIF
176 x 112
30
176 x 144
25
CIF
352 x 240
30
352 x 288
25
VGA
640 x 480
30
640 x 480
25
4CIF
704 x 480
30
704 x 576
25
Full D1
720 x 480
30
720 x 576
25
NOTE
When enabling simultaneous H.264 and MJPEG video streaming
at Full D1 resolution, the total FPS of these 2 video streams will
be about 30 FPS. For example, if MJPEG is set as 10 FPS, then
H.264 must be set as 20 FPS.
Video Viewing
•
DynaStream™ for automatic frame rate
adjustment
• Adjustable image size and quality
• Timestamp and text overlay
Audio
Audio Input
1 Line-in or MIC-in, RCA connector
Audio Output
1 Line-out, RCA connector
Network
Protocols TCP, UDP, HTTP, SMTP, FTP, Telnet, NTP, DNS,
DHCP, UPnP, RTP, RTSP, ICMP, IGMPv3, QoS (ToS),
SNMP (V1/V2c/V3), DDNS, Modbus/TCP
Ethernet
1 10/100BaseT(X) auto negotiation speed RJ45 port,
or 1 100BaseFX fiber port (SC connector)
Optical Fiber
100BaseFX
Multi Mode
Single Mode
Wavelength
1300 nm
1310 nm
Max. TX
-10 dBm
0 dBm
Min. TX
-20 dBm
-5 dBm
RX Sensitivity
-32 dBm
-34 dBm
Link Budget
12 dB
29 dB
Typical Distance
5 km
a
4 km
b
40 km
c
Saturation
-6 dBm
-3 dBm
a.
50/125μm, 800 MHz*km fiber optic cable
b. 62.5/125μm, 500 MHz*km fiber optic cable
c. 9/125μm, 3.5 PS/(nm*km) fiber optic cable
