IP Surveillance
2
© Moxa Inc. All rights reserved. Updated Apr. 18, 2016. Specications subject to change without notice. Please visit our website for the most up-to-date product information.
Ordering Information
Package Checklist
• VPort 364A video encoder
• 2 5-pin terminal blocks for 2 power inputs
and 2 relay outputs
• 1 8-pin terminal block for 4 DIs
• 1 5-pin terminal block for the RS-
232/422/485 PTZ control port
• Quick installation guide (printed)
• Documentation and software CD
• Warranty card
Available Models Port Interface
Standard Temp. Range
(0 to 60°C)
Wide Temp. Range
(-40 to 75°C)
10/100/1000
BaseT(X)
Multi-mode,
SC Connector
Single-mode,
SC Connector
VPort 364A VPort 364A-T
1 – –
VPort 364A-M-SC VPort 364A-M-SC-T
– 1 –
VPort 364A-S-SC VPort 364A-S-SC-T
– – 1
Optional Accessories (can be purchased separately)
SoftNVR-IA: 64-channel IP surveillance software for industrial automation applications
DR-4524: 45W/2A, 24 VDC power supply, with universal 85 to 264 VAC input
DR-75-24: 75W/3.2A, 24 VDC power supply, with universal 85 to 264 VAC input
DR-120-24: 120W/5A, 24 VDC power supply, with 88 to 132 VAC/176 to 264 VAC input by switch
MDR-40-24: 40W/1.7A DIN-rail 24 VDC power supply with universal 85 to 264 VAC input, -20 to 70°C operating temperature
MDR-60-24: 60W/2.5A DIN-rail 24 VDC power supply with universal 85 to 264 VAC input, -20 to 70°C operating temperature
WK-46: Wall-mounting kit
RK-4U: 19-inch rackmount set
Dimensions
Unit: mm (inch)
Top View
Rear View
Side ViewFront Views
30.5 (12.0)
30.5 (12.0)
55 (21.7)
108 (42.5)
51.75 (20.4)
64 (25.2)
80.05 (31.7)
15.25
(6.0)
20
(7.9)
20
(7.9)
73 (28.7) 73 (28.7)
73 (28.7)
105 (41.3)
135 (53.1)
135 (53.1)
PAN/TILT/ZOOM
PTZ Camera Control: Via RS-232/422/485 PTZ port
PTZ Control Functions: PAN, TILT, ZOOM, FOCUS, moving speed,
preset position (max. 25 positions), and 24 custom commands
PTZ Function Updates: Driver upload supported
Supported Device Protocols: Pelco D, Pelco P, Dynacolor DynaDome,
Cohu, Custom Camera
Transparent PTZ Control: Control PTZ cameras with legacy PTZ
control panel or keyboard connected to a PC or VPort decoder
Security
Password: User level password protection
Filtering: By IP address
Environmental Limits
Operating Temperature:
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Vibration:
IEC 60068-2-6, 2 to 13.2 Hz: 2 mm (peak-peak); 13.2 to 100 Hz: 0.7g;
1.50 hrs/axis
IEC 60068-2-6, 3 to 9 Hz: 7 mm (peak-peak); 9 to 150 Hz: 1.0g;
1.86 hrs/axis
Shock: IEC 60068-2-27, 20g/11ms
Altitude: 2000 m
Ingress Protection: IEC 60529, IP30
Standards and Certifications
Safety: UL 60950-1
EMI: CISPR 22, FCC Part 15B Class A
EMS:
EC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
MTBF (mean time between failures)
Time: 465,000 hrs
Standard: Telcordia SR332
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Minimum Viewing System Requirements
CPU: Pentium 4, 2.4 GHz or above
Memory: 512 MB memory or above
OS: Windows XP/2000 with SP4 or above, Windows Vista, Windows 7
Browser: Internet Explorer 9.x or above
Multimedia: DirectX 9.0c or above
Software Development
VPort SDK PLUS: Includes CGI commands, ActiveX Control, and API
library for customized applications or system integration for third-party
developers (the latest version of SDK is available for download from
Moxa’s website).
Standard: ONVIF
