Hotpoint-Ariston KIS 644 DD Z S [7/24] Start up and use

! The position of the corresponding gas burner or

electric hotplate* is shown on every knob.

Gas burners

Each burner can be adjusted to one of the following

settings using the corresponding control knob:

• Off

Maximum

Minimum

To turn on one of the burners, place a lighted match

or lighter near the burner, press the knob all the way

in and turn it anti-clockwise to the "High" setting.

On those models fitted with a safety device, the

knob must be pressed in for about 6 seconds until

the device that keeps the flame lit warms up.

On those models fitted with an ignitor, the ignition

button, identified by the

symbol, must first be

pressed and then the corresponding knob pushed

all the way in and turned anti-clockwise to the "High"

setting.

Some models are equipped with an ignition button

incorporated into the control knob. If this is the case,

the ignitor is present, but not the button.

To light a burner, simply press the corresponding

knob all the way in and then turn it anti-clockwise to

the "High" setting, keeping it pressed in until the

burner lights.

! If a flame is accidentally extinguished, turn off the

control knob and wait for at least 1 minute before

trying to relight it.

To switch off the burner, turn the knob in a clockwise

direction until it stops (when reaches the “•” position).

Start-up and use

Only available on certain models.

Practical advice on using the burners

To ensure the burners operate efficiently:

• Use appropriate cookware for each burner (see

table) so that the flames do not extend beyond

the bottom of the cookware.

• Always use cookware with a flat base and a

cover.

• When the contents of the pan reach boiling point,

turn the knob to minimum.

Burner ø Cookware diameter (cm)

Fast (R) 24 - 26

Semi Fast (S) 16 - 20

Auxiliary (A) 10 - 14

To identify the type of burner, refer to the designs in

the section entitled, "Burner and Nozzle

Specifications".
