User’s Manual 2-3

The Grand Tour

Right side

The following figure shows the computer's right side.

The right side of the computer

1. Optical Disc Drive 2. Optical Disc Drive LED

Optical Disc Drive The computer is configured with a full-size optical

disc drive module that lets you run either 12 cm

(4.72") or 8 cm (3.15") discs without using an

adapter. See the Optical Disc drive section in this

chapter for technical specifications on each drive

and Chapter 4, Operating Basics, for information

on using the drive and caring for discs.

Optical Disc Drive

LED

This indicator lets you know when the Optical

Disc Drive is being accessed.
