Vitek VT-1908 [3/6] English

Save these instructions. Read rules for safe operation carefully.

Important note: Please save color box. Returned goods will not be accepted if not

packed in original color box. Thank you!

WARNINGS

1. Before connecting the appliance, check that the power supply at home correZ

sponds to the voltage indicated on the appliance.

2. Do not immerse the appliance in any liquid and do not use it near showers or baths.

3. Do not touch the appliance with wet or dumphands.

4. Do not use extensions on bathroom or shower, unless with particular care.

5. Do not leave the appliance within reach of children or irresponsible persons without

supervision.

6. Before carrying out any cleaning operation always disconnect the appliance form

the mains power supply, by removing the plug or switching it off.

7. Beware tot the cable is not damaged.

8. Do not pull the supply cable or the appliance to remove the plug from the socket.

9. Do not pull the supply cable or the appliance to remove the plug from the socket.

10. The users should not replace the supply cable and/or the plug or this appliance. In

case of damage, or for the replacement apply only to a specialized technician.

11. Do not use the appliance for different purposes.

12. The appliance is not intended for use by young children or infirm persons without

supervision.

13. Young children should be supervised to ensure that they do not play with the appliZ

ance.

ASSEMBLY INSTRUCTIONS

1. Loosen and remove the 4 screws from the cross bar (1). Assemble the cross bars by

placing one over the other.

2. Place the flange at the bottom of the base tube (3) on the cros bar (1) and insert the

4 screws. Make sure that the holes line up and tighten the 4 screws.

3. Adjust telescopic tube (4) to desired height lock in place by tighten knob.

4. Remove the rear grill (6), grill nut (7) and mount the rear grill. Make certain that the

holes in the grill fit snugly over the prongs protruding from the motor housing (8).

Install the grill nut (7) and hand tighten.

5. Insert the fan blade onto the motor shaft (10) and make sure that the fits as far back

on the shaft as possible.Tighten the blade spinner (11) into place to secure the blade

(9) onto the shaft. The blade spinner (11) is tightened by turning counterZclockwise.

6. Mount the front grill (12) onto the rear grill (6) with all clips open. Line up the top fixed

clip at the 12 O`Clock position and make sure that the two halves of the grill are even.

Then securely close the clips so that they hold the grill firmly and evently together.

ENGLISH

VT-1908.qxd 02.12.02 16:35 Page 6
