M-Audio eKeys 49 [4/12] Before you connect your keyboard
![M-Audio eKeys 49 [4/12] Before you connect your keyboard](/views2/1020762/page4/bg4.png)
Evolution eKeys
49
Keyboard User Manual
4
Your Evolution eKeys
49
package should contain the following items:
If any of the above listed items are missing, please contact the retailer you purchased the
product from.
This instruction manual covers the operation of the eKeys
49
USB keyboard. We do not
explain how to set it up, however with third party music software, most programs will work
straight away with the eKeys
49
keyboard.
To learn about the included software PictureBoard, Music Teacher and Sound Studio,
please insert the eKeys
49
Installer CD-Rom and click “Software Installation”. Once in-
stalled you can read more about how to operate these great programs in their respective
help menus.
You are probably eager to plug in your eKeys
49
keyboard and get started, but it’s
sensible to check the installation documentation first.
You can power the keyboard either via USB or an optional external power supply. Use
only one method at a time.
1. Check that the on/off button on the back of the unit is set to “Off”.
2. Plug in the USB cable provided with the eKeys
49
keyboard to a free USB port
on your computer.
3. Plug in the other end of the USB cable to the USB socket on
the eKeys
49
keyboard.
The single USB cable not only powers the keyboard but also sends MIDI data to and from
your computer system.
If you are using Windows XP or Mac OS X you can now simply switch the power position
to “on”. Because the eKeys
49
keyboard is class compliant it will work with out any further
installation.
• Evolution eKeys
49
USB keyboard
• User Manual
• eKeys
49
Installer CD-ROM
• USB cable
What’s In The Package?
About The Manual
Before You Connect Your Keyboard…
Power & Connection Via USB
Windows XP & Mac OS X
21
Evolution eKeys
49
Keyboard User Manual
00 Bank Select
01 Modulation
02 Breath Control
03 Controller 3
04 Foot Control
05 Porta Time
06 Data Entry
07 Channel Volume
08 Balance
09 Controller 9
10 Pan
11 Expression
12 Effects Controller 1
13 Effects Controller 2
14 Controller 14
15 Controller 15
16 Gen Purpose 1
17 Gen Purpose 2
18 Gen Purpose 3
19 Gen Purpose 4
20 Controller 20
21 Controller 21
22 Controller 22
23 Controller 23
24 Controller 24
25 Controller 25
26 Controller 26
27 Controller 27
28 Controller 28
29 Controller 29
30 Controller 30
31 Controller 31
32 Bank Select LSB
33 Modulation LSB
34 Breath Control LSB
35 Controller 35
36 Foot Control LSB
37 Porta Time LSB
38 Data Entry LSB
39 Channel Volume LSB
40 Balance LSB
41 Controller 41
42 Pan LSB
43 Expression LSB
44 Controller 44
46 Controller 46
47 Controller 47
48 Gen Purpose 1 LSB
49 Gen Purpose 2 LSB
50 Gen Purpose 3 LSB
51 Gen Purpose 4 LSB
52 Controller 52
53 Controller 53
54 Controller 54
55 Controller 55
56 Controller 56
57 Controller 57
58 Controller 58
59 Controller 59
60 Controller 60
61 Controller 61
62 Controller 62
63 Controller 63
64 Sustain Pedal
65 Portamento
66 Sostenuto
67 Soft Pedal
68 Legato Pedal
69 Hold 2
70 Sound Variation
71 Resonance
72 Release Time
73 Attack Time
74 Cut-off Frequency
75 Controller 75
76 Controller 76
77 Controller 77
78 Controller 78
79 Controller 79
80 Gen Purpose 5
81 Gen Purpose 6
82 Gen Purpose 7
83 Gen Purpose 8
84 Portamento Control
85 Controller 85
86 Controller 86
87 Controller 87
88 Controller 88
89 Controller 89
90 Controller 90
92 Tremelo Depth
93 Chorus Depth
94 Celeste (De-tune)
95 Phaser Depth
96 Data Increment
97 Data Decrement
98 Non-Reg Param LSB
99 Non-Reg Param MSB
100 Reg Param LSB
101 Reg Param MSB
102 Controller 102
103 Controller 103
104 Controller 104
105 Controller 105
106 Controller 106
107 Controller 107
108 Controller 108
109 Controller 109
110 Controller 110
111 Controller 111
112 Controller 112
113 Controller 113
114 Controller 114
115 Controller 115
116 Controller 116
117 Controller 117
118 Controller 118
119 Controller 119
Channel Mode Messages
120 All Sound off
121 Reset all Controllers
122 Local Control
123 All Notes Off
124 Omni Off
125 Omni On
126 Mono On (Poly Off)
127 Poly On (Mono Off)
Extra RPN Messages
128 Pitch Bend sensitivity
129 Fine Tune
130 Coarse Tune
131 Channel Pressure
Standard MIDI Controller numbers (MIDI CC's)
