TX-6610

1-Port Gigabit GPON Terminal User Guide

LAN

A device is connected to the LAN port.

Flashing

The LAN port is transmitting or receiving data.

Off

No device is connected to the LAN port.

1.3.2 The Back Panel

Figure 1-2

 ON/OFF: The switch for the power.

 POWER: The Power plug is where you will connect the power adapter.

 RESET: There are two ways to reset the Terminal's factory defaults.

Method one: With the Terminal powered on, use a pin to press and hold the Reset button for

at least 5 seconds. And the Terminal will reboot to its factory default settings.

Method two: Restore the default setting from Management  Factory Defaults of the

Terminal's Web-based utility.

 GPON: The GPON is where you will connect the fiber.

 LAN: Through the port, you can connect the Terminal to your PC or the other Ethernet

network devices.
