Tp-Link M7300 [2/2] Charging the m7300

Tp-Link M7300 [2/2] Charging the m7300
Safety Information
LED Display
Charging the M7300
Note: The M7300 is fully charged when the (Battery LED) is solid green.
5V/1A
(Recommended)
Via the Wall Charger Via a Computer
Method 2
Method 1
Please read and follow the above safety information when operating the device. We
cannot guarantee that no accidents or damage will occur due to improper use of the
device. Please use this product with care and operate at your own risk.
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Do not use the device where wireless devices are not allowed.
Precaution: Explosion risk in case of battery substitution by one different.
Battery disposable according to instructions.
FAQ(Frequently Asked Questions)
Q2. What should I do if I cannot log into the
web-management page?
Verify that your device is connected to the M7300.
Verify that you have entered http://tplinkmifi.net or http://192.168.0.1
correctly.
Verify that your device is set to obtain an IP address automatically.
Q1. Is there any other alternative to manage the M7300
besides the tpMiFi app?
A. You can manage the M7300 by using its web management page.
1. Connect your Wi-Fi device to the M7300’s wireless network.
2. Open your web browser and type http://tplinkmifi.net or
http://192.168.0.1 into the address bar, then enter the default password
admin, and click Login.
Q3. How do I restore the M7300 to its factory default
settings?
A. While the M7300 is powered on, remove the cover. Use a pin to
press and hold the Reset button until all LEDs turn on momentarily.
Note: Resetting the device to its factory defaults will clear all
previous configuration.
A1. Check PIN status
Refer to Q1 to log into the web-management page on your phone. If
the current SIM card status is "PIN Locked", you will need to unlock it
using the PIN code.
A2. Verify the ISP parameters
1. Refer to Q1 to log into the web-management page on your phone.
Go to Dial-up > View Profile Details and verify the parameters (i.e.
APN, Username, and Password) provided by your ISP are correctly
entered.
2. If not, return to the Dial-up page and create a new profile with the
correct information, then choose the new created profile from the
Profile List.
A3. Check the Data Roaming settings
1. If your SIM card is operated in a roaming service area, refer to Q1 to
log in to the web-management page on your phone.
2. Go to Dial-up and enable the Data Roaming option.
A4. Check Mobile Data
Refer to Q1 to log into the web-management page on your phone.
Go to Dial-up to verify that Mobile Data is On. If not, enable this
option.
A5. Check Data Limit
Refer to Q1 to log into the web-management page on your phone.
Go to Device > Data Usage Settings to check whether your data
usage has exceeded the Total/Monthly allowance.
Q4. What should I do if the Internet Connection LED
doesn’t light up (cannot access the Internet)?
The LEDs will turn off automatically after 15 seconds. Please press the
Power button to turn them on again.
On
Red
Blinking Green
On
On
Status IndicationLED
The Wi-Fi connection is on.
The M7300 is connected to the Internet.
The M7300 is on.
The battery level is less than 10%.
The M7300 is charging.
http://tplinkmifi.net
Login
admin
Phone
PC
