Tp-Link T1600G-28TS (TL-SG2424) [3/5] Specifications

www.tp-link.com

Specifications

Datasheet

T1600G-28TS (TL-SG2424)

100-240VAC, 50/60Hz

Fanless

CE, FCC

17.3 x 7.1 x 1.7 in. (440 x 180 x 44 mm), 19-inch Rack mount Steel Case, 1U Height

Operating Temperature: 0℃~40℃(32℉~104℉); Storage Temperature: -40℃~70℃(-40℉~158℉);

Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing

56Gbps

41.7Mpps

16k

1.5MB

9216Bytes

Product Picture

Model

Physical Features

Connector

Power Supply

Fan Quantity

Certication

Dimensions (W x D x H)

Environment

Performance

Switch Capacity

Forwarding Rate

Mac Address Table

Package Buer Memory

Jumbo Frame

Hardware Features & Performance

Software Features

10/100/1000Mbps

RJ45 Port

Gigabit SFP Port

32Gbps

23.8Mpps

T1600G-28TS (TL-SG2424)

L2+ Features

Static Routing

– Up to 32 static route entries

Link Aggregation

– Support 802.3ad LACP

– Support static link aggregation

– Up to 14 aggregation groups, containing 8 ports per group

Spanning Tree Protocol(STP)

– IEEE 802.1D Spanning Tree Protocol

– IEEE 802.1W Rapid Spanning Tree Protocol

L2 Switching Features

– IEEE 802.1S Multiple Spanning Tree Protocol

– STP Security: Loop back detection, TC Protect, BPDU

Filter/Protect, Root Protect

Multicast

– Support IGMP Snooping V1/V2/V3, up to 256 groups

– Support multicast VLANs, IGMP Immediate Leave,

Unknown IGMP Throttling, IGMP Filtering, Static

Multicast IP

VLAN

– Support IEEE802.1Q with 4k VLANs simultaneously (out of 4K

VIDs)

– Support MAC based VLAN, protocol based VLAN

IEEE 802.3x ow control for Full Duplex mode and

backpressure for Half Duplex mode
