To ensure the normal communication of the factory switch, the default VLAN of all ports is set to
VLAN1. VLAN 1 cannot be deleted.
The following entries are displayed on this screen:
Port Based VLAN Configuration
Port Based VLAN
Configuration:
Enable or disable Port Based VLAN mode.
VLAN ID:
Enter the ID number of VLAN. It ranges from 2 to 32.
Port:
Displays the port number.
Member:
Click the check box to select the port of the VLAN
. It is
multi-optional.
If this field is checked, it indicates the port belongs
to the current VLAN.
Note:
A VLAN cannot be the subset or superset of the other VLANs.
7.3 802.1Q VLAN
On this page you can configure 802.1Q VLAN feature and view the related settings.
Choose the menu VLAN→802.1Q VLAN to load the following page.
