Aten CS1922 [2/3] Features

SOHO & SMB Solutions

Features

• 2/4-port DisplayPort KVMP™ Switch with USB 3.1 Gen1 hub and 2.1 surround sound audio

• One USB console controls 2/4 computers and 2 USB peripherals

• Computer selection via front panel pushbuttons, hotkeys and mouse

• Independent switching of KVM, USB, and Audio focus

• Superior video quality – 4K UHD (3840 x 2160 @ 60 Hz) and 4K DCI (4096 x 2160 @ 60 Hz)

• 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates

• DisplayPort 1.2 compliant, HDCP compliant

• Supports HD audio through DisplayPort

• Full bass response for high-quality 2.1 channel surround sound systems

• Power On Detection – if a computer is powered off, the CS1922 / CS1924 automatically switches to the next powered-on

computer

• Multi-Stream Transport (MST) allows multiple monitors through a single DisplayPort connector

• Dual-Mode DisplayPort technology (DP++) supports HDMI and DVI signals via an externally powered DisplayPort-to-HDMI/

DVI DP++ adapter

• Hot pluggable – add or remove computers without powering down the switch

• Keyboard emulation/bypass feature supports most gaming keyboard

• Mouse emulation/bypass feature supports most mouse drivers and multifunction mice

• Multi-platform support – Windows, Mac and Linux

• Multilingual keyboard mapping supports English, Japanese, French and German keyboards

• Mac keyboard support and emulation

• Auto Scan Mode for monitoring all computers

• Firmware upgradeable

Note:

1. Mouse port switching is only supported under mouse emulation mode with a USB 3-button mouse wheel.

2. HD audio through DisplayPort cannot be switched independently.

3. MST requires two monitors capable of DisplayPort 1.2 daisy-chaining, or use of a powered DisplayPort MST Hub. The PC

source must be DisplayPort 1.2 compliant. A DisplayPort v1.1a display can be the last display in a DisplayPort v1.2 chain.

4. Dual-Mode DisplayPort technology (DP++) does not require an active adapter for most single display setups. Active

DisplayPort adapters are recommended if you are unsure of the video source's DP++ compatibility.

5. PC keyboard combinations emulate Mac keyboards. Mac keyboards only work with their own operating system.

USB

DisplayPort

USB 3.0

Audio

KVM

Console

PC 1

PC 4

CS1924 (Front)

CS1924 (Rear)
