Chapter 1. Introduction

3. MST requires two monitors capable of DisplayPort 1.2 daisy-

chaining, or use of a powered DisplayPort MST Hub. The PC

source must be DisplayPort 1.2 compliant. A DisplayPort v1.1a

display can be the last display in a DisplayPort v1.2 chain.

4. Dual-Mode DisplayPort technology (DP++) does not require an

active adapter for most single display setups. Active DisplayPort

adapters are recommended if you are unsure of the video source's

DP++ compatibility.

5. PC keyboard combinations emulate Mac keyboards. Mac

keyboards only work with their own operating system.
