Aten CS1642A [43/54] Chapter 6
![Aten CS1642A [43/54] Chapter 6](/views2/1211061/page43/bg2b.png)
35
Chapter 6
The Firmware Upgrade Utility
The Windows-based Firmware Upgrade Utility (FWUpgrade.exe) provides a
smooth, automated process for upgrading the CS1642
A / CS1644A’s firmware.
The Utility comes as part of a Firmware Upgrade Package that is specific for
each device. New firmware upgrade packages are posted on our website as new
firmware revisions become available. Check the website regularly to find the
latest packages and information relating to them:
http://www.aten.com
Before you Begin
To prepare for the firmware upgrade, do the following:
1. Go to our Internet support site and choose the model name that relates to
your device (CS1642
A / CS1644A) to get a list of available Firmware
Upgrade Packages.
2. Choose the Firmware Upgrade Package you want to install (usually the
most recent), and download it to the computer connected to port 1 on the
CS1642
A / CS1644A.
3. If you have a DCC mode installation, remove the cable connected to the
DCC port, which connects the two CS1642
A / CS1644A units, and set both
DCC switches to Host.
4. Shut down all other computers connected to the CS1642
A / CS1644A
installation, except the computer connected to port 1.
5. Invoke Firmware Upgrade Mode (see Firmware Upgrade Mode, page 27).
The front panel LEDs flash together to indicate Firmware Upgrade Mode
is in effect.
