Altusen™ Enterprise Solutions
2
Features
New KN Series Exclusive
• High grade security – supports FIPS 140-2 level 1 security standards
• Extreme virtual media speed – 2 x faster virtual media transmission speed
• Advanced FPGA graphics processor – with an HD resolution of 1920 x 1200
• Simultaneously share one local console and two/four/eight independent connections to the attached servers
Hardware
• High port density – RJ-45 connectors and Cat 5e/6 cable for up to 32 ports (KN2132VA / KN4132VA / KN8132V) in a 1U
housing or 64 ports (KN8164V / KN4164V) in a 2U housing
• Laptop USB Console (LUC) – A dedicated USB port directly connects to a laptop for easy Console operation
• Two/four/eight our or eight separate buses for remote KVM over IP access
• Two 10/100/1000 Mbps NICs for redundant LAN or two IP operation
• Blade server support
• Supports PS/2, USB, Sun Legacy (13W3) and serial (RS-232) connectivity
• Local console provides USB keyboard and mouse support
• Supports multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
• Audio enabled
• Dual Power Supply
• High video resolution – up to 1920 x 1200 @ 60Hz with 24-bit color depth at the switch’s local console and on remote
session displays
• Monitor and control up to 64 computers on a single level, or control up to 512 computers in a cascade*
* Cascade-compatible KVM Switches include the following: CS9134, CS9138, CS88A, KH1508, KH1516, KH1508A, and
KH1516A
Management
• Up to 64 user accounts – up to 32 users simultaneously share the control
• Green IT-Fan speed varies according to temperature
• Event logging and Windows-based Log Server support
• Critical system event notication via SMTP email; SNMP trap and Syslog support
• Customizable events notication
• Firmware upgradeable
• Out-of-Band Access-Modem dial-in/dial out/dial back support
• Adapter ID Function: Stores port information allowing administrators to relocate the servers to different ports, without
having to re-configure the adapters and switches
• Port Share Mode allows multiple users to gain access to a server simultaneously
• Integration with ATEN CC2000 Centralized Management Softwar and CCVSR Video Session Recording Software
• Power Association enables the switch’s KVM ports to be associated with ATEN PDUs power outlets for remote power
management
• IPv6 capable
Ease-to-Use Interface
• ATEN Exclusive Panel Array Mode™ simultaneously monitoring for both local console operators and remote access users
• Local Console, browser-based, and AP GUIs offer a unied Multilanguage interface to minimize the user training time and
increase productivity
• Multiplatform client support (Windows, Mac OS X, Linux, Sun)
• Multi-browser support: Internet Explorer, Chrome, Firefox, Safari, Opera, Mozilla, Netscape
• Browser-based UI in pure Web technology allows administrators to perform administrative tasks without pre-installed Java
software package required
• Users can launch multiple virtual remote desktop sessions to control multiple servers during the same login
• Full-screen or sizable and scalable Virtual Remote Desktop
• Keyboard/Mouse Broadcast – keyboard and mouse inputs can be duplicated on all the attached servers
• Video syncing with the local console – local console monitor’s EDID information stored on the KVM Adapter Cables for
display resolution optimization
